User Manual

24
Mnemonics
Default Color
P
D
dISP
2ONE
F1
F2
P
D
Pro
NO
Pro
dISP
2ONE
dSP
Mn
Colr
Mn
Grn
Advanced Menu Mode Only
Mnemonics
Green
Backlight
Assignment
Mnemonics
Orange
Backlight
Assignment
Mnemonics
Red Backlight
Assignment
Mnemonics
Green-Orange
Backlight
Assignment
Mnemonics
Red-Orange
Backlight
Assignment
Mnemonics
Red-Green
Backlight
Assignment
Grn
Mn
NONE
OrNG
Mn
NONE
rEd
Mn
NONE
GnOr
Mn
NONE
rdOr
Mn
NONE
rdGn
Mn
NONE
MNEMONICS DISPLAY COLOR
Grn OrNG rEd
Enter the desired Mnemonics Display color.
Grn
= Green
OrNG
= Orange
rEd
= Red
The following programming steps are only available in the Advanced
Operating Mode.
These parameters allow the mnemonic backlights to change color, or alternate
between two colors when the mapped parameter is activated. When multiple
backlight assignments are programmed for a particular zone, the color priority
is defined as follows (from Lowest to Highest): Grn, OrG, rEd, GnOr, rdOr, rdGn
BACKLIGHT ASSIGNMENT SELECTIONS
NONE
= Backlight color change disabled
Out1
= Output 1
Out2
= Output 2
Out3
= Output 3
Out4
= Output 4
ALr
= Alarm
MAN
= Manual Control Mode
The following two programming steps are only available when the Backlight
Assignment is configured as an Alarm (Alr). These steps apply to each of the six
different backlight color assignment parameters.
ALARM LOGIC MODE
SNGL And Or
The PAX2C supports three different modes when an output is
assigned as an alarm:
SNGL
= Any single alarm
And
= Allows multiple alarms to be mapped to an output
using AND Boolean logic. For example: If AL1
and AL2 are active, the output will energize.
Or
= Allows multiple alarms to be mapped to an output
using OR Boolean logic. For example: If AL1 or
AL2 are active, the output will energize.
ALARM MASK ASSIGNMENT
NO YES
Selects the alarms to be logically combined per the Alarm Logic
Mode selection. Any alarms configured as YES will be used in the
Boolean logic calculation. If the Alarm Logic Mode is assigned as
Single (SNGL), only one alarm may be selected at a time.
MNEMONICS GREEN BACKLIGHT ASSIGNMENT
NONE Out1 Out2 Out3 Out4 ALr MAN
Select the parameter to be used to activate the mnemonic Green
backlight.
MNEMONICS ORANGE BACKLIGHT ASSIGNMENT
NONE Out1 Out2 Out3 Out4 ALr MAN
Select the parameter to be used to activate the mnemonic Orange
backlight.
MNEMONICS RED BACKLIGHT ASSIGNMENT
NONE Out1 Out2 Out3 Out4 ALr MAN
Select the parameter to be used to activate the mnemonic Red
backlight.
MNEMONICS GREEN-ORANGE BACKLIGHT ASSIGNMENT
NONE Out1 Out2 Out3 Out4 ALr MAN
Select the parameter to be used to activate the mnemonic Green-
Orange backlight.
MNEMONICS RED-ORANGE BACKLIGHT ASSIGNMENT
NONE Out1 Out2 Out3 Out4 ALr MAN
Select the parameter to be used to activate the mnemonic Red-
Orange backlight.
MNEMONICS RED-GREEN BACKLIGHT ASSIGNMENT
NONE Out1 Out2 Out3 Out4 ALr MAN
Select the parameter to be used to activate the mnemonic Red-
Green backlight.
Colr
UAn
rEd
LGIC
UAn
SNGL
ASEL
UAn
NO
An
Grn
Mn
NONE
OrNG
Mn
NONE
rEd
Mn
NONE
GnOr
Mn
NONE
rdOr
Mn
NONE
rdGn
UAn
NONE
display parameTers: ZOne COnfiguraTiOn - mnemOniCs (Mn)
