display parameTers (dISP)
Display
Intensity
Display
Contrast
Display
Rate
Menu
Mode
Basic Mode
Reset
F1
F2
P
D
Pro
NO
Pro
dISP
dISP
CNFG
dLEU
dSP
4
dCnt
dSP
7
dSPt
dSP
2
CNFG
dSP
bSIC
rSEt
dSP
NO
display parameTers: general COnfiguraTiOn (CNFG)
DISPLAY SELECT
CNFG ZONE LOCS HILO COdE
Select the display parameters to be programmed.
dISP
CNFG
DISPLAY INTENSITY LEVEL
0 to 4
Enter the desired Display Intensity Level (0-4) by using the arrow
keys. The display will actively dim or brighten as the levels are
changed. This parameter can also be accessed in the Display,
Parameter or Hidden Loops when enabled.
DISPLAY CONTRAST LEVEL
0 to 15
Enter the desired Display Contrast Level (0-15) by using the arrow
keys. The display contrast / viewing angle will actively adjust up or
down as the levels are changed. This parameter can also be accessed
in the Display, Parameter or Hidden Loops when enabled.
DISPLAY UPDATE RATE (/SEC)
1 2 5 10 20
This parameter configures the display update rate. It does not
affect the response time of the setpoint output or analog output option
cards.
OPERATING MODE
bSIC AdUC
This parameter configures the unit to operate in Basic or Advanced
Mode. Basic mode offers a reduced menu structure geared towards
simpler applications that may not require the more advanced features
of the PAX2C.
Basic Mode (bSIC):
Maximum of four alarms
Configuration of Display Color Zones is limited to a default
color (no dynamic changing of zone colors based on
mapped parameters)
Advanced Mode(AdUC):
Maximum of sixteen alarms
Full configuration on all seven Display Color Zones
The following programming step is only available when switching from
Advanced Operating Mode to Basic Operating Mode. The PAX2C Factory
default is Basic Operating Mode.
BASIC MODE RESET
NO YES
Resets the unit back to Basic Operating Mode factory defaults.
Warning: Any Advanced Operating Mode configuration in
the unit that is not supported in Basic Operating Mode
will be cleared and reset back to factory defaults.
