Cellular Configuration
2.1.5.2 VerifyingIPConnectivity
First,checktomakesurethatyourdeviceisconnectingtothecellularnetworkandobtaininganIPaddress.
NavigatetotheWebUIStatusscreenshownbelow:
Ifyourscreenlookssimilartotheoneshownabove,youarehavingsignalreceptiondifficulties.Youcanfurtherverifythis
condition
byexaminingtheLEDsignalmeter.
SN6000units:ObservethesignalLEDasshownbelow.
Signal
OFF Nosignalavailableorsignalstrengthisbelow‐100dBm
ON Excellentsignalstrength=greaterthan‐69dBm
FLASH
Fast:Every300ms=‐79to‐70dBm
Medium:Every600ms=‐89to‐80dBm
Slow:Every1200ms=‐99to‐90dBm
