Logical volume "new_logical_volume" created
1.4. Creating the File System
The following command creates a GFS file system on the logical volume.
[root@tng3-1 ~]# gfs_mkfs -plock_nolock -j 1 /dev/new_vol_group/new_logical_volume
This will destroy any data on /dev/new_vol_group/new_logical_volume.
Are you sure you want to proceed? [y/n] y
Device: /dev/new_vol_group/new_logical_volume
Blocksize: 4096
Filesystem Size: 491460
Journals: 1
Resource Groups: 8
Locking Protocol: lock_nolock
Lock Table:
Syncing...
All Done
The following commands mount the logical volume and report the file system disk space usage.
[root@tng3-1 ~]# mount /dev/new_vol_group/new_logical_volume /mnt
[root@tng3-1 ~]# df
Filesystem 1K-blocks Used Available Use% Mounted on
/dev/new_vol_group/new_logical_volume
1965840 20 1965820 1% /mnt
2. Creating a Striped Logical Volume
This example creates an LVM striped logical volume called striped_logical_volume that stripes
data across the disks at /dev/sda1, /dev/sdb1, and /dev/sdc1.
2.1. Creating the Physical Volumes
Label the disks you will use in the volume groups as LVM physical volumes.
Caution
This command destroys any data on /dev/sda1, /dev/sdb1, and /dev/sdc1.
[root@tng3-1 ~]# pvcreate /dev/sda1 /dev/sdb1 /dev/sdc1
Physical volume "/dev/sda1" successfully created
Physical volume "/dev/sdb1" successfully created
Physical volume "/dev/sdc1" successfully created
2.2. Creating the Volume Group
The following command creates the volume group striped_vol_group.
1.4. Creating the File System
