Chapter 5. LVM Configuration
Examples
This chapter provides some basic LVM configuration examples.
1. Creating an LVM Logical Volume on Three
Disks
This example creates an LVM logical volume called new_logical_volume that consists of the
disks at /dev/sda1, /dev/sdb1, and /dev/sdc1.
1.1. Creating the Physical Volumes
To use disks in a volume group, you label them as LVM physical volumes.
Caution
This command destroys any data on /dev/sda1, /dev/sdb1, and /dev/sdc1.
[root@tng3-1 ~]# pvcreate /dev/sda1 /dev/sdb1 /dev/sdc1
Physical volume "/dev/sda1" successfully created
Physical volume "/dev/sdb1" successfully created
Physical volume "/dev/sdc1" successfully created
1.2. Creating the Volume Group
The following command creates the volume group new_vol_group.
[root@tng3-1 ~]# vgcreate new_vol_group /dev/sda1 /dev/sdb1 /dev/sdc1
Volume group "new_vol_group" successfully created
You can use the vgs command to display the attributes of the new volume group.
[root@tng3-1 ~]# vgs
VG #PV #LV #SN Attr VSize VFree
new_vol_group 3 0 0 wz--n- 51.45G 51.45G
1.3. Creating the Logical Volume
The following command creates the logical volume new_logical_volume from the volume group
new_vol_group. This example creates a logical volume that uses 2GB of the volume group.
[root@tng3-1 ~]# lvcreate -L2G -n new_logical_volume new_vol_group
