Button Images
Chapter 7 Customizing Graphics and Color 85
Updating Button Images
The default button images have a height of 24 pixels and a width of 122 pixels. If the new
button image uses a different pixel height and width, these specifications must be changed
in all files in the
clients/dsgw/html directory where the image is referenced:
•
maintitle.html
•
authtitle.html
•
searchtitle.html
•
csearchtitle.html
•
newentrytitle.html
Changing the default filename of a button
.gif file requires updating the filename in all
files where the image is referenced.
stsearch_on.gif Used on the searchtitle.html page.
adsearch_off.gif Used in the maintitle.html,
authtitle.html, searchtitle.html, and
newentrytitle.html pages.
adsearch_on.gif Used on the csearchtitle.html page.
newentry_off.gif Used in the maintitle.html,
authtitle.html, csearchtitle.html, and
searchtitle.html pages.
newentry_on.gif Used on the newentrytitle.html page.
authen_off.gif Used in the maintitle.html,
searchtitle.html, csearchtitle.html,
and newentrytitle.html pages.
authen_on.gif Used on the authtitle.html page.
NOTE Any image used to replace button image must be a true .gif image.
Images in other formats (PICT, EPS, BPX, TIFF) will not appear as
intended.
Table 7-1 Button Images (Continued)
Button Image Description
