Technical data

VERSION 1.0
© 2010 RED.COM, INC. NOVEMBER 23, 2010
A-4
A1.4 RED STATION REDMAG 2.5”
The following shows the technical data for RED STATION REDMAG 2.5”.
Dimensions
Height: 1.48" (37.65 mm)
Width: 5.33” (135.4 mm)
Depth: 4.78” (121.3 mm)
Weight
0.95 lbs (0.43 kg)
Environment
No exposure to heat
No exposure to vibration
No exposure to strong electric or magnetic fields
Operating Temperature
Maximum: 50 - 104°F (10 - 40 °C)
Humidity
Operating: 20 - 80 %, non-condensing
Non-Operating: 10 - 90 %, non-condensing
Air
Dust-Free
Power
5V DC, 2A
Connection Cable(s)
DC Power Coupler Cable, length: 2” (50.8 mm)
eSATA Data Cable, length: 24” (610 mm)
FW800-FW800 Cable, length: 24” (610 mm)
FW800-FW800 Cable, length: 2” (50.8 mm)
USB + 5V DC Power Cable, length: 24” (610 mm)
NOTE: Only use power supply included with RED STATION REDMAG 2.5”.
