Technical data

VERSION 1.0
NOVEMBER 23, 2010 © 2010 RED.COM, INC.
A-1
A APPENDIX
This section provides technical details about RED STATION Base, RED STATION CF, RED STATION
REDMAG 1.8” and RED STATION REDMAG 2.5”.
A.1 TECHNICAL DATA
A1.1 RED STATION BASE
The following shows the technical data for RED STATION Base.
Dimensions
Height: 1.75” (44.45 mm)
Width: 5.33” (135.4 mm)
Depth: 4.78” (121.3 mm)
Weight
0.95 lbs (0.43 kg)
Environment
No exposure to heat
No exposure to vibration
No exposure to strong electric or magnetic fields
Operating Temperature
Maximum: 50 - 104°F (10 - 40 °C)
Humidity
Operating: 20 - 80 %, non-condensing
Non-Operating: 10 - 90 %, non-condensing
Air
Dust-Free
Power
5V DC, 5A
Connection Cable
DC Power Coupler Cable, length: 2” (50.8 mm)
NOTE: Only use power supply included with RED STATION Base.
