FireWire cable between each module and the computer. The computer will then recognize

each module individually through a single FireWire connection.

• USB – Connect USB + 5V DC Power Cable between RED STATION module and computer. It is

not necessary to connect the integrated 5V power connector to RED STATION module 5V DC IN

connector.

8. Insert CF card, 1.8” or 2.5” Hard Drive into corresponding RED STATION module slot.

9. RED STATION is now connected, go to 3.2 OPERATION OF RED STATION for operation instruc-

tions.

3.1.2 CONNECTING RED STATION MODULE STAND-ALONE

1. Remove RED STATION module (RED STATION CF, RED STATION REDMAG 1.8” or RED STATION

REDMAG 2.5”) from packaging.

2. Locate four (4) rubber pads and install onto 4 pegs on bottom of RED STATION module.

3. Place RED STATION module on a firm, flat surface.

4. Connect RED STATION module to the computer using the desired connection.

IMPORTANT: DO NOT connect more than one data cable between an individual RED STATION

module and the computer (e.g. USB + eSATA + FireWire) at the same time.

• eSATA – Connect e-SATA Data Cable between RED STATION module and computer. Connect

supplied power adapter to RED STATION module and plug it into a power outlet.

NOTE: When connecting to the computer using eSATA, it may take up to 15 seconds before

the media is displayed on the computer.

NOTE: The USB + 5V DC Power Cable 5V power connector can be used to power RED STA-

TION module for eSATA connection in place of power adapter in situations where a wall out-

let is not available.

• FireWire '8800-'8

800 Cable – Connect FW800 cable between RED STATION module and

computer.

NOTE

: When connecting RED STATION module to the computer using FireWire Cables the

FireWire cables provide power for RED STATION module, it is not necessary to connect the

supplied power adapter, however recommended for optimal performance.

• USB – Connect USB + 5V DC Power Cable between RED STATION module and computer. Plug

the integrated 5V power connector into RED STATION module 5V DC IN connector to provide

power.

NOTE: If connecting to the computer using a different Mini-USB cable than provided, the

supplied power adapter can be used to power RED STATION module.

5. Insert CF card, 1.8” or 2.5” Hard Drive into corresponding RED STATION module slot.

6. RED STATION is now connected, go to 3.2 OPERATION OF RED STATION for operation instruc-

tions.
