2.5.2.1 ESATA
When connecting RED STATION module(s) to the computer using the eSATA Data Cable in stand-alone
configuration, the 5V DC 2A Power Adapter must be plugged into the RED STATION module 5V DC IN
connector. If RED STATION modules(s) are used in conjunction with RED STATION Base, the 5V DC 2A
Power Adapter does not need to be plugged into RED STATION module(s), as it is powered through
RED STATION Base.
IMPORTANT: ONLY Silicon Image or Highpoint SATA cards will connect to RED STATION mod-
ules through eSATA at this time.
2.5.2.2 FIREWIRE
When connecting RED STATION module(s) to the computer using the FireWire Cable in stand-alone
configuration, it is not necessary to connect the 5V DC 2A Power Adapter as power is provided through
the FireWire Cable, however it is recommended for optimal performance. If RED STATION module(s) are
used in conjunction with RED STATION Base, RED STATION module(s) are powered through RED
STATION Base.
2.5.2.3 USB
When connecting RED STATION module(s) to the computer using the USB + 5V DC Power Cable in
stand-alone configuration, the integrated 5V DC power connector must be plugged into the RED
STATION module(s) 5V DC IN connector and to a power source. If RED STATION module(s) are used in
conjunction with RED STATION Base, the integrated 5V DC connector does not need to be plugged into
RED STATION module(s), as it is powered through RED STATION Base.
