2.5 CONNECTION CABLES

The following information outlines the connection and power cables supplied with RED STATION Base,

RED STATION CF, RED STATION REDMAG 1.8” and RED STATION REDMAG 2.5”.

For detailed procedures on connecting RED STATION Base, RED STATION CF, RED STATION RED-

MAG 1.8” and RED STATION REDMAG 2.5”, refer to 3.1 SETUP OF RED STATION.

2.5.1 RED STATION BASE

To power RED STATION Base the following power source is included:

- 5V DC 5A Power Adapter and wall plug

For RED STATION Base to power RED STATION modules, the following cable is included:

- DC Power Coupler Cable, length: 2” (50.8 mm)

2.5.2 RED STATION COMPACT FLASH / RED STATION REDMAG 1.8” / RED

STATION REDMAG 2.5”

Operation with RED STATION Base

To power RED STATION CF, RED STATION REDMAG 1.8” or RED STATION REDMAG 2.5” through

RED STATION Base or additional modules, the following cable is included:

- DC Power Coupler Cable, length: 2” (50.8 mm)

Stand-Alone Operation

To power RED STATION CF, RED STATION REDMAG 1.8” or RED STATION REDMAG 2.5” when con-

necting to computer using eSATA Data Cable in stand-alone configuration, the following power source

is included:

- 5V DC 2A Power Adapter

Data Connections

To connect RED STATION CF, RED STATION REDMAG 1.8” or RED STATION REDMAG 2.5” to a com-

puter, the following cables are included:

- eSATA Data Cable, length: 24” (610 mm)

- FW800-FW800 Cable, length: 24” (610 mm)

- USB + 5V DC Power Cable, length: 24” (610 mm)

Daisy-Chain

To connect RED STATION CF, RED STATION REDMAG 1.8” or RED STATION REDMAG 2.5” to addi-

tional modules, allowing for a single FireWire cable connection to the computer, the following cable is

included:

- FW800-FW800 Cable, length: 2” (50.8 mm)
