2.2 RED STATION COMPACT FLASH
This section provides information detailing RED STATION CF.
2.2.1 OVERVIEW OF THE FRONT
This section provides information detailing the front of RED STATION CF.
Figure 2-3: RED STATION CF – Front
Table 2-3: RED STATION CF Connector/Component Descriptions – Front
NO. ITEM DESCRIPTION
1 CF SLOT Compact Flash card slot
2 LED
Indicates power status; Red LED lights up when
RED STATION CF is powered and turned ON;
flickers as media is being read
1
2
