2 OVERVIEW
This section provides information detailing RED STATION Base, RED STATION CF, RED STATION
REDMAG 1.8” and RED STATION REDMAG 2.5”.
2.1 RED STATION BASE
This section provides information detailing RED STATION Base.
2.1.1 OVERVIEW OF THE FRONT
This section provides information detailing the front of RED STATION Base.
Figure 2-1: RED STATION Base - Front
Table 2-1: RED STATION Base Component Descriptions – Front
NO. ITEM DESCRIPTION
1 LED
Indicates power status; Red LED lights up when
RED STATION Base is powered and turned ON
