HR9000PKG Two Vehicle Specific Headrests With 7” LCD Monitors and Built-In DVD Player for Rear Seat Entertainment R Operation Manual 128-7689
IMPORTANT An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function when the vehicle is in ‘park’ or when the vehicle’s parking brake is applied.
HR9000PKG System The HR9000PKG system contains two vehicle specific headrests. Each has a 7" Monitor and built-in DVD Player. This system allows the users to either watch individual DVD’s or watch the same DVD on both monitors. Both users can also share an A/V source connected to either the AV2 or AUX inputs. The full function remote control can operate either unit by selecting MI or M2 on the remote. Quick Start Guide 1. 2. 3. 4.
CONTROLS AND INDICATORS DIAGRAM Control Function Descriptions for M1 and M2 Monitor M1 / M2 Panel Control 1 1. DVD disc insertion slot 2. EJECT Button 3. Power Indicator LED 4. POWER Button 5. SOURCE Button 6. SCREEN MODE Button 7. PLAY Button 8. STOP Button 9. IR Transmitter LEDS 10. Game Port 11.
HR9000PKG SYSTEM OVERVIEW 1) The HR9000PKG is a versatile audio / video system which includes two monitors with built-in DVD players. They can accept an Audio / Video input to either the AV2 or AUX inputs. 2) The M1 Monitor is comprised of a 7" TFT LCD monitor with built-in DVD player that allows the user to select from DVD, A/V1, AV2, or AUX/GAME sources. The M1 monitor has a built-in infrared audio transmitter (CH A) for use with the supplied two-channel wireless headphones (CH A).
7) The M1 and M2 Monitor will accept an audio / video input through either the AV2 input (located on the FMM inter-connect or the AUX (use with supplied AV adaptor) input located on the front of the unit. The audio / video device could be a video game system, video camera, or other input device. Note: If the Game Controller is plugged in and an AUX source is plugged in to the AUX input, the AUX input will override the Game Controller. To use the Game Controller, unplug the AUX input.
REMOTE CONTROL OPERATION POWER MONITO R SELEC T M2 M1 1 34 SOURCE 2 1 2 3 4 5 6 7 8 9 – + 33 32 0 Lift for battery installation 3 4 5 Battery Cover MUTE PIX ENTER 6 MENU SET UP 7 RETUR N REP EAT A-B 8 Battery Installation 10 24 DISPLA Y FM M ON /OF F CH AN NE L SE LE CT AUDIO ZOO M ANGLE M1 ONLY 11 12 13 1) Turn the remote control face down. Using a fingernail, lift the battery cover off. 2) Install two “AAA” batteries.
REMOTE CONTROL FUNCTION DESCRIPTIONS * Function control is available on the unit and remote control. NOTE: To control the individual units (M1 Monitor / M2 Monitor) press either M1 or M2 before pressing any other button. For example, to turn M1 Monitor ON, press M1 and then the power button. 1. POWER Button* – Press this button to turn M1 or M2 Monitor on. Press the button again to turn M1 or M2 Monitor OFF. 2. SOURCE Button* – Press this button to select the available sources.
10. DISPLAY Button – Press to display the current disc information while the disc is playing. Press the cursor (pqtu) buttons to highlight the desired option. For title and chapter selection use the number buttons to enter the desired title or chapter number for angle, audio, and subtitle. Press the ENTER button repeatedly to change the item. Title Chapter 00:00:14 DVD Angle Title -/Chapter 1/1 Angle 1/1 5.1 Ch ENG 1/1 Audio Audio Stop Off Subtitle Subtitle 11.
18. SCAN BACKWARD (7) Button – Press to search in a backward direction. Press repeatedly to change the search speed from 2, 4, 8, 20 times the normal speed. 19. SCAN FORWARD (8) Button – Press to search in a forward direction. Press repeatedly to change the search speed from 2, 4, 8, 20 times the normal speed. 20. PLAY (u) Button* – Press to activate the play mode while a disc is loaded in the disc compartment. 21. ANGLE Button – Press to display and select different camera angles in DVD mode.
28. RIGHT (u) Button – Use this button to shift right in the menu options. 29. PIX Button (PICTURE SELECT) – Each time this button is pressed, the on screen picture adjustment displays the “adjustment bar” for BRIGHTNESS, CONTRAST, COLOR or TINT. Once the desired adjustment bar is displayed, use the VOLUME(+)/ VOLUME(–) button to adjust the setting. The display will automatically turn off if no adjustments are made within 6 seconds, or is any other button is pressed. 30.
OPERATION INSTRUCTION Button Functions (M1/M2 Unit) 6 There are six (6) buttons on the front of the HR9000M1 M1 unit and HR9000M2 M2 unit as below. 1. POWER Button – To turn the unit ON/OFF. 2. SOURCE Button – Press this button will select between DVD, AV1, AV2 and AUX/GAME. 3. SCREEN MODE Button – Press this button will select between Wide(16:9), Normal(4:3) aspect ratio or screen off (display OFF). 4. PLAY Button – Press this button to start playback. AUX GAME PORT 5.
SETTINGS AND ADJUSTMENTS The Setup Menu contains features and options that let you customize your DVD player. For example, you can set a language for the onscreen display, limit playback for children. Using the Setup Menu 1. Press the SETUP button on the remote. The Setup Menu appears on the screen as shown per diagram. Language Language Setup Language Video Video Setup Rating Rating Setup OSD Menu Video Rating English English French Spanish German Italian 2.
LANGUAGE SETUP Language for On-Screen Display OSD MENU: The OSD MENU setup allows you to select the language for the on-screen display. The user can either select English, French, Spanish, German or Italian for the OSD language. Language OSD Menu Video Rating English English French Spanish German Italian Video Rating VIDEO SETUP TV Display The TV DISPLAY setup allows you to adjust screen setting (aspect ratio).
RATING SETUP Rating This item allows you to limit the content of movie playback from G to Adult. The lower the value, the more strict the control. G PG PG – 13 R NC – 17 Adult The rating level can only be changed when the displayed lock is open. For first time use, key in the default password (3308) and press enter.
Playing Audio DVDs 1. When playing an audio CD, the DISPLAY banner appears automatically. It displays the track playing, the total tracks on the disc, and the elapsed time of the track playing. 2. Selecting a Track You can skip to a specific track by using the numbers keys. Key in the desired track number and press ENTER. 3. Using the REPEAT feature The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: • SINGLE – repeat the track that is playing.
Playing MP3 Discs MP3 is a format for storing digital audio. An audio CD-quality song can be compressed into the MP3 format with very little loss of quality, while taking up much less space. CD-R discs that have been encoded in MP3 format can be played on your DVD player. The DVD player plays the songs in the order they were burned on to the disc. Selecting Folders and Songs When an MP3 is loaded in the player, the navigation menu appears automatically. 1.
Program Play To use the program play option, you must create a play list of songs in the order you want them to play. NOTE: Once you begin adding songs from a folder to create your play list, you cannot add songs from a different folder. 1. Choose the PROG-PO option for the PLAY MODE. 2. Highlight and enter the folder you want to program. 3. Add songs to the program list by pressing ENTER once the song is highlighted.
DVD Basics To get the optimum use out of the DVD section, make sure you read this section completely. Regional Coding Both the DVD player and DVDs are coded by region. These regional codes must match in order for the disc to play. If the codes don’t match, the disc won’t play. This unit’s code is region 1. Other regional codes cannot be played in this unit. The unit will display “WRONG REGION”. Types of Discs your DVD will play • DVD* disc - DVD discs which contain video.
Audio / Video Inputs and Outputs AV Output* The AV output will provide the DVD signal from the M1 unit. This output can be connected to an additional monitor or video display. * The AV output jack (P/N 112-3678) for the FMM interconnect box is supplied and used for connections. Source Feature M1 Sources: DVD, AV1, AV2, AUX DVD - Select DVD to view the internal DVD player. AV1 - Select AV1 to view the source that is selected on the M2 satellite monitor.
CONNECTING THE GAME CONTROLLER 1. Plug the game controller (arrow facing up) into the game port on the front of the headrest monitor. 2. Press the source button(s) on the front panel or the source button on the remote until “GAME”* is displayed. *NOTE: The AUX and the Game inputs are shared on the HR9000. When switching sources if the game controller is not plugged in the OSD will display “AUX” when the game controller is plugged in it will switch to “GAME”.
TROUBLESHOOTING SOLUTION PROBLEM Poor in vehicle radio reception — Check the condition of the vehicle’s radio antenna. — Verify that the antenna is fully raised. — Verify that it that the FM Modulator is turned OFF by using the remote. IR sensor inoperative — Verify that the batteries in the remote are fresh. — Verify that the remote sensor eye is not obstructed. — Verify that Master Monitor or Satellite Monitor has been selected correctly.
CAUTION 1. 2. 3. 4. Keep the monitor clean and dry. Always seek qualified personnel to perform repairs. Never attempt your own repairs. Do not drop the monitor or expose to strong impacts. Do not expose to direct sunlight for extended periods of time. MONITOR SPECIFICATIONS 1. Type : TFT Active Matrix LCD 2. Resolution : 1440 (W) x 234 (H) 3. Pixels : 336,960 4. Back Light : Edge Light Tube 5. Power Source : +12 VDC 6. Power Consumption : 35W For 2 Monitors + 2 DVD 7.
ADVENT LIMITED WARRANTY Applies to ADVENT Mobile Video Products R AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that, should this product or any part thereof (except game controllers), under normal use and conditions, be proven defective in material or workmanship within 36 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
© 2006 ADVENT,150 Marcus Blvd.
