Datasheet

www.recom-power.com
REV.: 0/2019 PD-4
DC/DC Converter
Specifications (measured @ Ta= 25°C, nom. Vin, full load and after warm-up unless otherwise stated)
Trim up
1 2 3 4 5 6 7 8 9 10 [%]
Vout
set
=
15.15 15.30 15.45 15.60 15.75 15.90 16.05 16.20 16.35 16.50 [VDC]
R
up
(E96) ≈
162k 78k7 49k9 36k5 28k 22k6 18k7 15k8 13k3 11k5 [W]
Trim up
11 12 13 14 15 16 17 18 19 20 [%]
Vout
set
=
16.65 16.80 16.95 17.10 17.25 17.40 17.55 17.70 17.85 18.00 [VDC]
R
up
(E96) ≈
10k 8k8 7k6 6k8 6k 5k3 4k6 4k1 3k6 3k2 [W]
RP12-11015SAR
Trim down
1 2 3 4 5 6 7 8 9 10 [%]
Vout
set
=
14.85 14.70 14.55 14.40 14.25 14.10 13.95 13.80 13.65 13.50 [VDC]
R
down
(E96) ≈
825K 402k 261k 191k 150k 124k 105k 88k7 76k8 68k1 [W]
Trim up
1 2 3 4 5 6 7 8 9 10 [%]
Vout
set
=
24.24 24.48 24.72 24.96 25.2 25.44 25.68 25.92 26.16 26.40 [VDC]
R
up
(E96) ≈
576k 280k 182k 133k 105k 84k5 69k8 95k3 52k3 45k3 [W]
Trim up
11 12 13 14 15 16 17 18 19 20 [%]
Vout
set
=
26.64 26.88 27.12 27.36 27.6 27.84 28.08 28.32 28.56 28.80 [VDC]
R
up
(E96) ≈
40k2 35k7 31k6 28k7 26k1 23k7 21k5 19k6 17k9 16k2 [W]
RP12-11024SAR
Trim down
1 2 3 4 5 6 7 8 9 10 [%]
Vout
set
=
23.76 23.52 23.28 23.04 22.8 22.56 22.32 22.08 21.84 21.60 [VDC]
R
down
(E96) ≈
4M99 2M43 1M62 1M18 931k 768k 649k 562k 487k 432k [W]
Trim up
1 2 3 4 5 6 7 8 9 10 [%]
Vout
set
=
12.12 12.24 12.36 12.48 12.60 12.72 12.84 12.96 13.08 13.20 [VDC]
R
up
(E96) ≈
205k 10k 64k9 47k5 36k5 29k4 24k9 20k1 17k9 15k8 [W]
RP12-11012SAR
Trim down
1 2 3 4 5 6 7 8 9 10 [%]
Vout
set
=
11.88 11.76 11.64 11.52 11.40 11.28 11.16 11.04 10.92 10.8 [VDC]
R
down
(E96) ≈
768k 383k 249k 182k 143k 118k 97k6 84k5 73k2 63k4 [W]
REGULATIONS
Parameter Condition Value
Output Accuracy ±1.0% max.
Line Regulation low line to high line, full load
single
dual
±0.2% max.
±0.5% max.
Load Regulation
0% to 100% load
single
dual
±0.2% max.
±1.0% max.
10% to 100% load
single
dual
±0.1% max.
±0.8% max.
Cross Regulation dual output only, assymetrical load 50%/100% full load ±5.0% max.
Transient Response
25% load step change
recovery time
200mVp-p
250µs typ.
continued on next page
RP12-AR
Series
