1. General Description

RTL8188CEBT

Combo mini-Card User Manual

Product specifications

2.3. Mini PCI Express Pin Assignment

Table 1. Mini PCI Express Pin Assignment

PIN# Pin Name

PIN# Pin Name

1 WAKE# YES 2 3.3Vaux YES

3 COEX1 YES 4 GND YES

5 COEX2 YES 6 +1.5V (Option) YES

7 CLKREQ# YES 8 UIM_PWR NC

9 GND YES 10

UIM_DATA

NC

11 REFCLK- YES 12

UIM_CLK

NC

13 REFCLK+ YES 14

UIM_RESET

NC

15 GND YES 16

UIM_VPP

NC

17 RESERVED NC 18 GND YES

19 BT_DISABLE# (Option) YES 20 W_DISABLE# YES

21 GND YES 22 PERST# YES

23 PERn0 YES 24 +3.3Vaux NC

25 PERp0 YES 26 GND YES

27 GND YES 28 +1.5V (Option) YES

29 GND YES 30 SMB_CLK NC

31 PETn0 YES 32 SMB_DATA NC

33 PETp0 YES 34 GND YES

35 GND YES 36 USB_D- YES

37 GND YES 38 USB_D+ YES

39 +3.3Vaux NC 40 GND NC

41 +3.3Vaux NC 42 LED_WWAN# NC

43 GND YES 44 LED_WLAN# YES

45 RESERVED NC 46 LED_WPAN# YES

47 RESERVED NC 48 +1.5V (Option) YES

49 RESERVED NC 50 GND YES

51 BT_DISABLE# (Option) YES 52 +3.3Vaux YES
