Caution: Make sure the lance (9) is
properly fixed to the gun (7).
3.
Attach the nozzles (10-15).
Caution: When attaching the nozzle
(10-15) the button (A) on the nozzle
(10-15) should come out again.
Check before activating the trigger
that the nozzle (10-15) is properly
fixed.
7.4 Water connection
IMPORTANT! Only use water without
any impurities. If there is a risk of sand
particles in the inlet water (i.e. from
your own well), an additional filter
should be mounted.
1.
Let the water run through the water
hose before connecting it to the
machine to prevent sand and dirt
from penetrating the machine. Note:
Check that the filter is fitted in the
water inlet pipe and that it is not
clogged up.
2.
Connect the water hose to the water
supply by means of the quick
connector (inlet water, max.
pressure: 10 bar, max. temperature:
40°C).
3.
Turn on the water.
7.5 Start/stop of the machine
The trigger gun (7) and lance (9) is
affected by a thrust during operation -
therefore always hold it firmly with
both hands.
IMPORTANT: Point the nozzle at the
ground.
1.
Check that the machine is in upright
position.
NOTE: Do not place the machine in
high grass!
2.
Release the trigger lock (8)
3.
Activate the trigger of the trigger
gun (7) and let the water run until
all air has escaped from the water
hose.
4.
Press the Start/stop switch (4).
5.
Activate the trigger of the trigger
gun (7).
6.
Always adjust the distance and thus
the pressure of the nozzle to the
surface, which is to be cleaned.
Do not cover the machine during
operation or use it in a room without
adequate ventilation!
NOTE: If the machine is left or not used
for 5 minutes, it must be switched off
on the start/stop switch (4) "O":
1.
Press the start/stop switch (4) "O".
2.
Disconnect the electrical plug (2)
from the socket.
3.
Shut off the water supply and
activate the trigger of the trigger
gun (7) to relieve the machine of
pressure.
4.
Lock the trigger gun (7).
When releasing the trigger of the
trigger gun (7), the machine
automatically stops. The machine will
2
A
1
3
