Never leave the device unattended
as long as the main switch is turned
on.
During work breaks the manual spray
gun should be secured by use of the
lock.
spray gun and the jet pipe as tightly
as possible.
If required, you should wear
appropriate protective clothing as
protection against spray.
Here there is a Danger of
Death
Never operate the device in rooms
where there is a risk of explosion.
Never touch the mains plug with wet
hands. As additional protection the
installation of a residual current
device (RCD) with a rated breaking
current of not more than 30mA is
recommended in the electric circuit
of the bathroom. Please consult a
qualified electrical engineer.
Before operating the device always
check the mains power cable, the
mains plug and high-pressure hose
for damage. Damaged cables must
be replaced immediately by an
approved qualified electrician. Also
damaged high-pressure hoses are to
be replaced immediately.
The following should be taken into
consideration when cleaning motor
vehicles: Tires and tire valves may
be damaged by the high-pressure jet
and then burst. The first indications
of this are discoloration of the tire.
Only the fan jet should be used. A
distance of at least 50cm should be
maintained during the cleaning
process.
Here there is Danger of
Injury
The jet of water emerging from the
high-pressure nozzle causes the
manual spray gun to recoil.
Please ensure you are standing in a
stable location. Hold the manual
7. OPERATION INSTRUCTIONS
7.1 Connection of garden hose
1.
Screw the water inlet coupling (1)
tight on to the water inlet.
Note: The inlet filter must always
be fitted in the water inlet pipe to
filter out sand, lime stone and
other impurities as these will
damage the pump valves.
Caution: Failure to fit the filter will
invalidate the guarantee.
2.
Connect the garden hose with a
standard quick coupling.
7.2 Mounting of high pressure hose
1.
Attach the high pressure hose (6) to
the trigger gun (7) and machine.
2.
Detach the high pressure hose by
pressing the pawl (A) or button (B).
A
B
7.3 Mounting of lance and nozzle
1.
Push the lance (9) into the trigger
gun (7).
2.
When inserted turn it.
