Installation Guide

13
(Fig. 27)
(Fig. 28)
(Fig. 26)
(Fig. 30)
(Fig. 31)
(Fig. 29)
11.
Cut the top cover (B) to length at the
stair angle (Fig. 26, 27, 28).
++++++++++++++++++++++++++++++
IF INSTALLING THE WOOD TOP
COVER (A) REFER TO STEP 3W ON
PAGE 14. ONCE COMPLETED
RETURN TO STEP 13 ON THIS PAGE.
++++++++++++++++++++++++++++++
12.
Snap the top cover (B) onto the top
beam (C) by rolling the cover to one side,
engaging the locking strip. Then, roll
the top cover (B) to the other side while
applying downward pressure. Work from
one end of the rail to the other until the
full length of the cover locks into place
(Fig. 29).
13.
Slide the top beam cover (E) up onto the
top beam (C), ensuring that it snaps into
place over its entire length and under the
top cover (B) (Fig. 30, 31).
