DIGITAL WIRELESS 9” LCD MONITORING SYSTEM WITH SD CARD RECORDING INSTRUCTION MANUAL
Features • Digital wireless technology provides excellent image quality and clarity • Interference free, secure and private signal • Up to 300ft wireless transmission range ① • Two-way audio communication • SD card recording • Safety warning feature notifies you when out of range • System expandable up to 4 cameras ② ① Maximum open space transmission range. The actual range is dependent upon building materials and other obstructions in path of wireless signal. ② Additional cameras sold separately.
Wireless Receiver Front Controls 1. LCD Screen – Displays video from the camera(s) or displays system operations. 2. Indication LEDs – Indicates the status of the system. There are 4 indication LEDs: NEW: Indicates new recorded video. FULL: Indicates that the SD card is full of memory. It is only available when Overwrite is disabled. SCAN: Indicates that the receiver is in scan mode (screen saver). AUTO REC: Indicates that the receiver is in auto recording mode.
9. TALK Button – Press down and hold this button to talk back to the camera which’s image is displayed on the screen. 10. Power Slide Switch – Slide the switch to ON or OFF position to switch on/off the receiver. 11. Microphone – Receives sounds from the area near the receiver and transmits sound from the receiver to the camera (only when TALK Button is pressed down and held). 12. SD Card Slot – Insert SD card to this SD card slot for both video and audio recording. 13.
Wireless Camera Front & Side Controls 1. Camera Antenna – Sends & receives signals to or from the receiver. 2. AC Adaptor Jack – Plug the AC adaptor to the jack for camera’s power supply. 3. Wall Mounting Bracket – Use the bracket to mount the camera on a wall or other flat surfaces. 4. IR LEDs – Infrared LEDs provide viewing in no/low light conditions 5. Lens – Catches the video in front of the lens and transmits video from camera to receiver. 6.
Installation Warnings Aim the camera(s) to best optimize the viewing area: Select a location for the camera that provides a clear view of the area you want to receive, which is free from dust, and is not in line-of-sight to a strong light source or direct sunlight. Avoid installing the cameras where there are thick walls, or obstructions between the cameras and the receiver. Night Vision This camera has built-in IR LEDs, which provides the camera with the ability to view images in no/low light conditions.
Remote Control The remote control is supplied to operate the receiver. It includes all the operations on the receiver except talking back to camera. Note: When using remote control, it is recommended to have it point at the IR reception port which is above the LCD screen. Quad – Press Quad button to view the images in quad mode. Press (Channel) A, (Channel) M or Quad button again to exit from quad mode. Menu –Press to access the receiver menu. Press the button again to exit.
Viewing Mode 1. Signal Indicator – The signal indicator shows the strength of the signal being received from the camera. Signal Indicators: 2. Recording Indicator – When the receiver is recording, the red indicator ●REC will be shown on the LCD screen. And under the indicator, you can see the name of the recorded file. 3. SD Card Indicator – When a SD card is inserted into the SD card slot, the indicator will be shown on the LCD screen. 4.
SD Card Recording The system is designed for SD card recording. You can manually record the video at your desire or the receiver records when there is motion detected by the cameras. Before recording, you need to insert a SD card to the SD card slot. The system can support the size of up to 16GB SD card. Recording Mode Auto Recording Press (Record) Motion button on the remote control to set the system to automatic recording mode.
Accessing Menu System The functions of the Menu button and navigation buttons/Enter button on the remote control are the same as the joystick and Menu button on the back of receiver. In this section we take the remote control as example to show the menu operation. Press the Menu button on the remote control to enter menu system. Use the navigating buttons to navigate up/down/left/right in the menu, and press the Enter button to confirm a setting or selection. Main Menu The Main Menu contains 4 submenus: 1.
- Schedule Record: Set the schedule recording time for each day. Time can be set from 00:00 to 23:59. Then select the menu ON to enable schedule recording. - Overwrite: Decide whether to cover the initial recorded files when SD card is full of memory. Pairing Menu The system comes with camera(s) that have already been paired. The pairing function assigns each camera to a different channel on the wireless receiver (up to 4 cameras), and is necessary for configuring additional cameras.
- AV Out: Select the TV system when outputting the video/audio to TV, DVR/VCR or other viewing/recording devices. - Screen Saver: 5 pictures are stored in the system. You can select one picture to make it be shown on the LCD screen in scan mode. Or you can select Blank screen to make the LCD screen display nothing in scan mode. - Alarm Volume: Receiver beeps to alert you when motion or RIGHT button to detected by camera. Press LEFT increase or decrease the volume of the audio alarm.
Camera Pairing The system comes with camera(s) that have already been paired. These cameras will communicate with the receiver once powered on. The pairing function assigns each camera to a different channel on the wireless receiver (up to 4 cameras), and is necessary for configuring additional cameras. NOTE: It is highly recommended to pair the cameras to the receiver before permanently mounting the cameras. 1. Power on the receiver by connecting it to power outlet with supplied 5V power adaptor. 2.
Troubleshooting If you have problems with the system, there is often a quick and simple solution. Please try the following: Problem No picture from a camera The picture is dropping Audio problems The picture is or has become choppy Solution 1. Check all connections to the camera. Make sure the adaptor is plugged in. 2. Make sure that the receiver is ON. 3. Make sure that the camera is in range of the receiver. 1. Move the camera closer to the receiver. 2.
Appendix #1 – System General Specifications Operating Frequency Range 2.400GHz~2.483GHz TX Power 14dBm RX Sensitivity -81dBm Type of Spread Spectrum Used FHSS Type of Modulation Used GFSK Data Rate 2Mbps Communication Range 100m Line of Sight Appendix #2 - Receiver Specifications Display Size/Type 9” TFT LCD Resolution H: 640 RGB, V: 234 Viewing Angle H: 140 degree, V: 130 degree A/V Output Resolution/ Frame Rate VGA/ QVGA Selectable Power Requirement 5.
Operating Temp Range -10~50 degree C Operating Humidity Range Within 85%RH Dimension 185mm x 68mm x 38mm Environment Rating IP56 Regulation Compliance FCC RoHS Compliance Yes Camera Housing Material Aluminum Note: The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. FCC NOTE: This device complies with Part 15 of the FCC Rules.
