User Manual

Item
Description
Accessory Number
1.
CYLINDER
BM1001
2.
CRANKSHAFTACCESSORY
BM1002
3.
CRANKCASE SET
BM1003
4.
PISTON ACCESSORY
BM1005+BM1028+BM1004+BM1027
5.
PROP HUB ACCESSORY
BM1023+BM1024+BM1016+BM1017
6.
BEARINGS
BM1012,BM1025
7.
IGNITION SET
BM1006
8.
WRIST PIN BEARING
BM1026
9.
REEDVALVE&INSULATOR
BM1011
10.
CARBURETOR
BM1008
11.
SPARK PLUG
BM1010
12.
MUFFLER
BM1007
13.
GASKET SET
BM1019+BM1020+BM1014+BM1009
14.
SCREW SET
T8
RCGF 10cc
Parameter:
Type : 2 cycle piston valve type gasoline engine for airplane
Displacement (cc) : 10cc (0.61 cu in)
Bore x Stroke (mm): 1.08 in (27.6mm)*0.67 in (17mm)
Carburetor : Walbro
Ignition : DC-CDI (Computer Controlled auto advance, electronic ignition
system)
Power supply: 4.8-8.4V
Maximum Output : 1.9 hp/1.4KW
Requires: Gasoline, 2-cycle oil, ignition battery & propeller
speed rang : 1800-12000rpm
Gasoline-Version : Pre-mixed Fuel, 25-40 (Gasoline):1 (recommended : 30:1)
(90% high otcane unleaded gasoline, Import gas into carbon fiber installations
valves)
Lubrication Oil : 2 cycle engine oil
Propeller : 13*7 9800 rpm; 14*6 9000rpm (Standard Two leafs prop)
recommended props :13 x 6, 14 x6,13X8,13X7.
Cooling System : Air Cooled
