Tour of the Receiver
FM ANT
IN OUT
IN OUT
IN OUT
REAR
120V 60Hz
SWITCHED 180W, 1.5A MAX
UNSWITCHED 180W, 1.5A MAX
(MONO)
CENTER
1
2
AM ANT
VIDEO
SUB WOOFER
OUT
AUDIO
SOURCE
VCR 2/
LD
MONITOR
OUT
CD TAPE/MDTV
VCR 1 DSS
VCR 2/
LD
VCR 1 DSS
AUDIO
300Ω
BAL
L
R
MAIN
L
R
SPEAKERS (8 ) AC OUTLETS
SURROUND SPEAKERS (4 MIN.)
AUDIO
L
R
L
R
Back Panel
AUDIO Connections Provides audio connections for
components such as a VCR, TV, CD player, laserdisc player or
tape player.
IN Provides audio input from another component.
OUT Sends audio output to another component, such as
a minidisc, tape player or VCR. Sends a signal to
the subwoofer.
VIDEO Connections Provides video connections for the
video portion of another component such as a VCR, TV or
RCA DSS
®
Receiver.
IN Provides video input from another video component.
OUT Sends video output to another video component
such as a VCR.
Monitor Out Sends video output to the TV.
SPEAKERS Provides connection to the speakers.
SURROUND SPEAKERS Provides connection for the
Surround Sound speakers.
AC Outlets One switched AC outlet and one unswitched AC
outlet provide A/C power outlets for other components.
FM ANT Provides connection for an FM antenna.
AM ANT Provides connection for an AM antenna.
