RS2005/07 EN rev.1 6/14/02 8:38 AM Page 3 u s e r m a POWER STANDBY n STEREO u a l RS2005/RS2007 It is important to read this instruction book prior to using your new product for the first time. Es importante leer este manual antes de usar por vez primera su euipo.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 4 FCC Information EN FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. In accordance with FCC requirements, changes or modifications not expressly approved by Thomson multimedia Inc.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 5 Safety Information CAUTION EN RISK OF ELECTRIC SHOCK DO NOT OPEN THE LIGHTNING FLASH AND ARROWHEAD WITHIN THE TRIANGLE IS A WA R N I N G S I G N ALERTING YOU OF "DANGEROUS VOLTAGE" INSIDE THE PRODUCT. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERS E RV I C E A B L E PA R T S I N S I D E . R E F E R S E RV I C I N G TO QUALIFIED SERVICE PERSONNEL.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 6 Getting Started EN Unpacking the system: Speaker Wire Connection You should have the following: • one main unit (with 2 main speakers); • one remote control; • one user’s guide; • one safety leaflet. • Owner and registration Card Push terminal tab down to insert wire. Release tab to lock wire in the terminal. NOTE: Make sure the insulation is completely removed from the ends of the speaker wires at all connection points.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 7 General Controls Main Unit POWER STANDBY STEREO PROG/ SET MINUTE MINUTE EN SKIP BACKWARD - Decrements radio frequency, goes to the previous CD track or setting mode. X-BASS - Turns X-Bass on/off. SLEEP - Selects sleep duration. PRESET • UP -In CD mode - Goes to the next CD track; selects the next program location. In Tuner mode - Selects the next preset station. In Clock or Timer mode - Increases hour and minute digit.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 8 General Controls EN Remote Control STANDBY MUTE TUNER TAPE VOLUME DISC1 DISC2 DISC3 + - PROG./SET PRESET TUNING REPEAT CLOCK BAND/APP PLAY/PAUSE SLEEP STEREO STOP TIMER REMAIN SHUFFLE X-BASS DISC SKIP INTRO STANDBY — Turns power on or off from standby mode. MUTE - Mutes audio output. TUNER — Selects radio tuner. TAPE — Selects tape player. VOLUME - or + - Decreases or Increases volume level.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 9 Display Settings EN Display Display Clock / Timer Setting the Clock 1. Press CLOCK twice. The hour flashes on the display. 2. Press HOUR - or + on the main unit or PRESET or on the remote control to set the hour and then press CLOCK to shift to minute digits. 3. Press MINUTE - or + on the main unit or PRESET or on the remote control to set the minute. 4. Press CLOCK to save settings. Note: • Press CLOCK to display the current time for about 2 seconds.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 10 Sound Features EN X-BASS Muting Audio Press X-BASS to turn on/off boosting the bass frequency. Press MUTE on the remote to cut the sound. (Remote Only) Volume Control Press VOL or on the main unit or VOLUME + or - on the remote control to adjust volume level. CD Player CD-R / RW Playing Discs This unit is compatible with CD-RW/ CD-R discs for playback.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 11 CD Player Shuffling the Play Order Playing a Program List Press SHUFFLE to turn on/off the playing of tracks in random order. While in PROGRAM mode (press PROG/SET to enter), press PLAY. Sampling Tracks Display and Edit Program List Press INTRO to play the first 10 seconds of each track on the current disc, all discs in the tray, or turn INTRO mode off. 1. While the CD player is stopped, press PROG/SET to enter PROGRAM mode. 2.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 12 Radio EN Selecting Tuner Band Auto Preset Programming 1. Press SOURCE on the main unit or TUNER on the remote control to enter Tuner (TU) mode. 2. Press BAND/APP to select between AM or FM radio band. Tip: Your audio system has 30 preset stations. Tuning to a Station Press SKIP FORWARD / SKIP BACKWARD on the main unit or TUNING or on the remote control to select frequency. Using Presets The tuner can be in either TUNE or PRESET mode.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 13 Tape Player Recording EN From Tuner PHONES Tape Player RECORD PLAY REWIND FAST FORWARD STOP/EJECT PAUSE Playing a Tape 1. Press SOURCE on the main unit repeatedly or TAPE on the remote to enter Tape mode (CA). 2. Press STOP/EJECT to open the cassette door. 3. Insert a tape into the door and push the door closed. 4. Press REWIND/FAST FORWARD to position the tape to the desired starting position. 5. Press PLAY to begin playback. 6.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 14 Troubleshooting Tips EN Problem Solution Problem Solution System will • Check power cord for a secure not turn on connection. • Unplug the unit for a moment, and then plug into power source again. • Check the outlet by plugging in another device. CD button will not respond, or does not change discs when you press DISC SKIP No sound Poor radio reception • Increase the volume setting. • Check connection to speakers.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 15 Maintenance Disconnect the audio system from the power source before performing any maintenance. Cleaning Clean the exterior of the system using a soft dust cloth. CD Player CAUTION! This system operates with a laser. It must be opened by only a qualified technician. Tape Player To prevent deterioration of sound quality, periodically open the door of each deck and clean the magnetic heads, pinch roller, and capstan with a cotton bud dipped in alcohol.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 16 Important Information EN Safety Precautions • Never open the cabinet under any circumstances. Any repairs or internal adjustments should be made only by a trained technician. • Never operate this product with the cabinet removed. •Do not use your System immediately after transporting it from a cold place to a warm place, as condensation may cause the system to malfunction. • Keep your unit away from humid areas and abnormally hot places.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 17 Limited Warranty (U.S.) EN What your warranty covers: • Defects in materials or workmanship. For how long after your purchase: • One year from date of purchase for labor and parts • Warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental firm, whichever comes first. What we will do: • Pay any Authorized RCA Audio Service Center the labor charges to repair your unit.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 18 Limited Warranty (U.S.) EN Limitation of Warranty: • THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON MULTIMEDIA INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 19 Limited Warranty (Canada) EN What your warranty covers: • Defects in materials or workmanship. For how long after your purchase: • One year from date of purchase for labor and parts • The warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental firm, whichever comes first. What we will do: • Pay any Authorized RCA Audio Service Center the labor charges to repair your unit.
RS2005/07 EN rev.1 6/14/02 8:38 AM Page 20 Limited Warranty (Canada) EN Limitation of Warranty: • THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON MULTIMEDIA LTD., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY. • REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. THOMSON MULTIMEDIA LTD.
