Recommended Tools Hex Drivers (1.5mm, 2mm, 2.5mm) Thread Lock Cross Wrench (M2, M3, M4) Long Nose Pliers Phillips Driver Tips for Assembly Use good quality hex drivers to avoid stripping screw heads. Use thread lock when putting metal screws into metal parts. Note: Steps marked with an asterisk (*) require thread lock. Use thread lock sparingly. Do not over tighten screws otherwise you may strip the thread.
All RC4WD products are warranted to be free of defects in materials and workmanship when new. Our limited warranty does not cover damages due to normal wear and tear, user error of assembly or installation, user modifications, user's failure to perform routine maintenance, addition of aftermarket parts or option parts. This warranty lasts as long as the original purchaser owns the product.
All of the hardware should be taken from Bag C ●1* M3 x 6mm Steps 2 to 5 should be done on both frame rails Metal parts can be found in Bag A ●2* M3 x 8mm 1 RC4WD TF2 LWB
Plastic parts can be found in Bag D ●3 M3 x 14mm ●4 M3 x 12mm ●5 M3 x 15mm Step Screw M3 Locknut 2 RC4WD TF2 LWB
●6* M3 x 10mm ●7* M3 x 8mm 3 RC4WD TF2 LWB
●8* M3 x 12mm M3 x 10mm ●9* M3 x 8mm 4 RC4WD TF2 LWB
●10* M3 x 10mm ●11* M3 x 8mm M3 Locknut M3 x 8mm M3 x 15mm M3 Locknut M3 x 15mm 5 RC4WD TF2 LWB
●12* M3 x 12mm M3 x 14mm M3 x 14mm ●13* M3 x 8mm M3 x 10mm M3 x 12mm M3 x 10mm M3 x 8mm 6 RC4WD TF2 LWB
●14* M3 x 10mm ●15* M3 x 8mm M3 x 8mm M3 x 8mm Countersunk Screw 7 RC4WD TF2 LWB
●16* M3 x 6mm Countersunk Screw ●17* M3 x 8mm Countersunk Screw 8 RC4WD TF2 LWB
●18* M3 x 14mm ●19-1 1 Optional (Not used) 2 Step 19-2 3 Step 24 9 RC4WD TF2 LWB
● 19-2 M3 x 6mm Countersunk Screw ●20* M3 Drive Shaft Pin 10 RC4WD TF2 LWB
●21* M3 x 6mm Countersunk Screw Bearing ●22 M3 x 8mm 11 RC4WD TF2 LWB
●23 M3 x 8mm Countersunk Screw Attach leaf springs to front and rear axles Note: The smaller helper leafs can be fitted below the main leaf to stiffen the suspension ●24 M3 x 16mm M3 Locknut Remove the screws first 12 RC4WD TF2 LWB
●25 M3 Locknut M3 x 15mm ● 26 M3 x 15mm M3 Locknut 13 RC4WD TF2 LWB
● 27 M3 x 6mm Countersunk Screw ● 28-1 80mm Shock M3 Locknut M3 x 18mm 2mm Spacer 14 RC4WD TF2 LWB
● 28-2 M3 Locknut 3mm Spacer M3 x 16mm ● 29 M3 12mm 100mm Shock 2mm Spacer M3 x 16mm 15 RC4WD TF2 LWB
● 30 M3 Drive Shaft Pin ● 31-1 16 RC4WD TF2 LWB
● 31-2 M3 x 10mm ● 32 M3 Drive Shaft Pin 17 RC4WD TF2 LWB
● 33 Locking Ring CORRECT ALIGNMENT INCORRECT ALIGNMENT Please check alignment when installing your drive shafts.
● 34 Short Drive Shaft M3 Drive Shaft Pin ● 35 M3 x10mm Threaded Rod M3 x15mm Threaded Rod 60mm Link 101mm Link 19 RC4WD TF2 LWB
● 36 Note: Servos are not included in this KIT.
● 38 M3 Locknut M3 x 10mm M3 x 22mm ● 39 21 RC4WD TF2 LWB
● 40 M3 x 10mm ● 41 M3 x 20mm Threaded Rod 35mm 22 RC4WD TF2 LWB
● 42 M3 x 10mm ● 43 M3 Locknut M3 x 14mm 23 RC4WD TF2 LWB
● 44 M3 x 15mm Set Screw ● 45 M3 x 15mm Set Screw 24 RC4WD TF2 LWB
● 46 Wheel disassembly shown 1. Insert internal beadlock ring into tire. 2. Install wheel front and back. NOTE: Ensure front and back side spokes align with each other. 3. Use the included longer hardware to help aid in tire and wheel installation. Be sure to slowly tighten the nuts on the longer hardware until you are able to begin installing the included shorter hardware. 4. Install the correct shorter length hardware into the remaining holes.
5. Begin to tighten the hardware in a star shape pattern to fully seat the tire to the wheel properly. 1 6 4 3 2 5 7. Now you can remove the longer hardware. 6. Your wheel and tire should be fully seated like shown. M2 x 14mm Cap Screw 8. Install the correct shorter hardware. 9. Completed assembly of your new wheels and tires.
● 47 Note: Body will need to be assembled prior to fitting. See Mojave ll LWB Body assembly instructions.
Drive it like you built it! 28 RC4WD TF2 LWB
Spare Parts Z-S0619 TF2 Parts Bag A Z-S0620 TF2 Parts Bag D Z-S0591 TF2 Hardware Bag C Z-B0029 TF2 Plastic Body Posts Z-S0592 TF2 Fuel Cell Radio Box Z-S0593 TF2 Bumper Mounts Z-S0594 TF2 Front Tube Bumper Z-S0595 TF2 Rear Tube Bumper Z-S0597 TF2 Shock Hoops Z-S0598 TF2 Tcase Mounts Z-C0018 TF2 Chassis Set Z-U0024 TF2 Scale Transfer Case Z-U0025 TF2 Scale 2 Speed Transmission Z-S0600 TF2 2mm Spacers Z-S0601 TF2 Yota Steering Links Z-A0058 Yota Front Axle Z-A0061 Yota Rear Axle Z-S0027 Yota 1/10 Axle Ring &
Optional Parts VVV-C0007 1/10 Metal Emblem for Tamiya Hilux Z-S0565 3 Link Kit For Trail Finder 2 Front Axle w/Panhard Setup Z-S1192 Front Inner Fender Set for Mojave / Hilux Body Z-S1091 Front Machined Winch Bumper for Trail Finder 2 Z-E0076 RC4WD 1/10 Baja Designs S8 LED Light Bar (120mm) Z-S1093 RC4WD Billet Aluminum Fuel Cell Radio Box (Black) Z-S1122 RC4WD Billet Aluminum Fuel Cell Radio Box (Red) Z-D0034 RC4WD 70mm Old Man Emu Nitrocharger Sport Shock by ARB Z-D0038 RC4WD 90mm Old Man Emu Nitrocharger
