Table 1-1 P25net CC Specifications
RS-232 Receive RS-232 Rx: Pin 1 on the D15F rear panel connector Channel 1-4
RS-232 Transmit RS-232 Tx: Pin 2 on the D15F rear panel connector Channel 1-4
Digital Ground Pin 9 on the D15F rear panel connector Channel 1-4
Ground reference for the RS-232 data lines.
Programmable I/O
DIN0 Programmable Input 0 (reserved) Pin 10 on the D15F rear panel
connector Channel 1-4
DIN1 Programmable Input 1 (reserved) Pin 3 on the D15F rear panel
connector Channel 1-4
DIN2 Programmable Input 2 (reserved) Pin 12 on the D15F rear panel
connector Channel 1-4
OUT0 Programmable Output 0 (reserved) Pin 4 on the D15F rear panel
connector Channel 1-4
IN3 Programmable Input 13 (reserved) Pin 3 on the D15F rear panel
connector Channel 1-4
FGND Ground reference for IN3
LED Display
S1 Green when 10MHz GPS Reference connected
DC Power A and B Green when DC power is at DC Inputs A and B
Channel Status For each supplied channel: Steady Green when controlled by BSC;
flashing otherwise.
Rx For each supplied channel: Orange when a valid P25 signal is received.
Tx For each supplied channel: Red when a signal is being transmitted
Physical
Size 1.75” H x 19” W x 12.4” D (4.4 x 48.3 x 31.5 cm).
Weight 5 pounds ( 2.3kg)
Operating Temperature 0 to +60 degrees C.
Storage Temperature -40 to +85 degrees C.
1.5 Equipment Supplied
Table 1-2 Equipment and Accessories Supplied
P25net CC Top Level Part Number Explanation
5060- 6 X 0 2 X 0
P25net
Family
# of Channels 1=Standard I/O
1=1 Channel 2=4 Wire AFSI
2=2 Channel
3=3 Channel
4=4 Channel
All units include:
