Datasheet

Fax-on-demand Fax ID Description
US only [phone] 3125 SCD
Outside US [phone] 3126 SCD-25/225
Visit our website at www.tycoelectronics.com
Users should independently evaluate the suitability of the product for their application.
Before ordering check with factory for most current data.
4-69 Molded Parts
Materials available
Material* Material description Precoating no. Adhesive part no.**
-3 Semirigid polyolefin /42 or /86 S-1017 or S-1048
-4 Flexible polyolefin /42 or /86 S-1017 or S-1048
-12 Viton N/A S-1255-04
-25 Fluid-resistant elastomer /42 or /86 or /225 S-1017 or S-1048 or S-1125
-100 Polyolefin, Zerohal /86 or /180 S-1030 or S-1048
*For more information, please see the appropriate material page in this section.
**For more information, please see Section 5 of this catalog.
Product dimensions (mm/in)
HJ PR
Min. Max. Min. Min. Min. Max.
Part -3, -4, -12, -25 -3, -4, -25 -12 -100 ±10% ±10%
number a b a a a b b b
202K121 24.0 (.95) 10.4 (.41) 24.0 (.95) 13.0 (.51) 14.0 (.55) 5.6 (.22) 38.0 (1.50) 21.0 (.83)
202K132 30.0 (1.18) 14.2 (.56) 30.0 (1.18) 14.0 (.55) 15.0 (.59) 5.9 (.23) 55.0 (2.17) 32.0 (1.26)
202K142 31.0 (1.22) 18.0 (.71) 31.0 (1.22) 16.0 (.63) 18.0 (.71) 7.1 (.28) 67.0 (2.64) 35.0 (1.38)
202K153 36.0 (1.42) 22.4 (.88) 36.0 (1.42) 19.0 (.75) 21.0 (.83) 8.4 (.33) 80.0 (3.15) 42.0 (1.65)
202K163 43.0 (1.69) 28.2 (1.11) 43.0 (1.69) 22.0 (.87) 25.0 (.98) 9.9 (.39) 99.0 (3.90) 61.0 (2.40)
202K174 60.0 (2.36) 35.1 (1.38) 60.0 (2.36) 35.0 (1.38) 39.0 (1.54) 15.7 (.62) 130.0 (5.12) 72.0 (2.83)
202K185 66.0 (2.60) 44.5 (1.75) 66.0 (2.60) 38.0 (1.50) 42.0 (1.65) 16.8 (.66) 170.0 (6.69) 90.0 (3.54)
UJOHWJWXY
±10% ±10% ±20% Min. ±20% ±20%
bbbbbb
202K121 12.0 (.47) 8.5 (.33) 1.6 (.06) .41 (.016) 24.0 (.94) 13.0 (.51)
202K132 12.0 (.47) 11.5 (.45) 1.8 (.07) .81 (.032) 24.0 (.94) 18.0 (.71)
202K142 20.0 (.79) 17.0 (.67) 1.8 (.07) .81 (.032) 32.0 (1.26) 25.0 (.98)
202K153 20.0 (.79) 19.5 (.76) 2.0 (.08) .81 (.032) 32.0 (1.26) 30. 0 (1.18)
202K163 20.0 (.79) 21.0 (.82) 2.2 (.08) .81 (.032) 52.0 (2.05) 30.0 (1.18)
202K174 20.0 (.79) 39.0 (1.53) 3.3 (.13) 1.02 (.040) 52.0 (2.05) 50.0 (1.97)
202K185 20.0 (.79) 51.5 (2.02) 3.8 (.15) 1.63 (.064) 52.0 (2.05) 70.0 (2.76)
Note: Coating is optional. As supplied dimensions appearing in table are for uncoated parts. When coating is added, entry diameters will be reduced by 1.5 mm (.06") max.
