PC Card Adapter CBS52U User’s Manual Dec. 2002 Rev.1.
CBS52U 1. Introduction........................................................................... 3 1-1. Package Content ....................................................................................... 3 1-2. System Requirements ............................................................................... 3 1-3. Restrictions ................................................................................................ 3 2. Installation ............................................................
2
1. Introduction This User’s Guide describes how to install the RATOC CBS52U PC Card Adapter (called CBS52U in this User’s Guide). The information in the README.TXT file on the CD-ROM may include the latest information. Be sure to read the file as well. Refer to our web site for the information on Linux. (http://www.ratocsystems.com/english/) 1-1.
2. Installation This chapter describes how to install the CBS52. If you have Windows XP, proceed to 2-1. If you have Windows Me,2000,98SE proceed to 2-3. 2-1. Installing on Windows XP If you install the CBS52 on Windows XP, you don’t need the bundled CD-ROM. Don’t use the CD-ROM. Turn off the PC and install the CBS52 into an available PCI slot. After installing it, turn on the PC. 1. Intall the CBS52 straight into an available PCI slot. 2.
2-2. Confirmation of the driver installation 1. Right-click on [My Computer] and select [Properties]. Click the [Hardware] tab and click the [Device Manager] button. Check there are two [Ricoh R/RL/5C476(II) or Compatible CardBus Controller] strings under the [PCMCIA adapters]. Double-click a [Ricoh R/RL/5C476(II) or Compatible CardBus Controller] string. 2. If you can find a [This device is working properly] under the [Device status], you have completed the installation successfully.
2-3. Installing on Windows Me/2000/98SE If you use a 16bit PC Card on Windows Me/2000/98SE, you need to install the driver from the bundled CD-ROM before installing the CBS52 into a PCI slot.If you don’t use a 16bit PC Card, you don’t need to install the driver from the bundled CD-ROM. Follow the steps through: (1) Running [Setup.
(1)Running [Setup.exe] at the CD-ROM Run [Setup.exe] at the CD-ROM before you install the CBS52. 1. Close other programs running on your PC. Run [Setup.exe]. 2. The installation program will start. Click [Next]. 3. If you agree on the License Agreement, click [Yes]. 4. Confirm the destination of the program, and click [Next]. 5. Select [No, I will restart my computer later] and click [Finish]. Shut down your PC.
(2)Installing the CBS52 into an available PCI slot Turn off the PC and install the CBS52 into an available PCI slot. After installing it, turn on the PC. 1. Intall the CBS52 straight into an available PCI slot. 2. Install the CBS52 into the PCI slot until the board seats firmly. 3. Fasten the CBS52 with screws, as shown below. (3)Installing the driver If you have Windows Me, proceed to (3-1). If you have Windows 2000, proceed to (3-2). If you have Windows 98SE proceed to (3-3).
(3-1)Windows Me If you start your PC after installing the CBS52, you are requested to restart your PC, as shown.Click [Yes] to restart your PC. Proceed to (4-1)Driver confirmation for Windows Me/98SE. (3-2)Windows 2000 If you start your PC after installing the CBS52, you are requested to restart your PC, as shown. Click [OK] to restart your PC. Proceed to (4-2)Driver confirmation for Windows 2000. (3-3)Windows 98SE 1. IIf you start your PC after installing the CBS52, the following wizard will appear.
3. Click [Finish] and restart your PC. Proceed to (4-1)Driver confirmation for Windows Me/98SE. (4)Driver Confirmation (4-1)Driver Confirmation for Windows Me/98SE 1. Right-click on [My Computer] and click the [Device Manage] tab. Check there are two [Ricoh RL5C476 CardBus Controller] strings under the [PCMCIA socket]. Double-click a [Ricoh RL5C476 CardBus Controller] string. 2.
3. Run [GetDrvVer.exe] at the [GetDrvVer] folder in the CD-ROM. You can know the version of the installed programs. You have now finished the installation. (4-2)Driver Confirmation for Windows 2000 1. Right-click on [My Computer] and select [Properties]. Click the [Hardware] tab and click the [Device Manager] button.Check there are two [Ricoh R/RL/5C476(II) or Compatible CardBus Controller] strings under the [PCMCIA adapters].
3. 12 Run [GetDrvVer.exe] at the [GetDrvVer] folder in the CD-ROM. You can know the version of the installed programs. You have now finished the installation.
3. Troubleshooting (1) How to uninstall the programs(Windows Me/2000/98SE users only) If you want to delete the programs installed from the bundled CD-ROM, follow the step: a. Double-click [My Computer]->[Control Panel]->[Add/Remove Programs] and select [Winroute]. Then, delete it. (Windows Me/98SE) (Windows 2000) b. Click [Yes].
c. Click [OK]. d. Click [OK]. Restart your PC. You have now completed deleting the programs. (2)How to update the programs(Windows Me/2000/98SE users only) If you have a latest program availabe through our web site, follow the steps to update the programs. A )Delete the programs fisrt, as described in step (1) B) Run a latest programs and follow on-screen instructions. (3)Troubleshooting Q. [PCMCIA Card Service]stirng appears with “!”marks in Windows Me. A. Restart your PC. Q.
4. Registration and Tech-support 4-1. How to Register We highly recommend to register yourself as our customer through our on-line registration. 1. On the Internet, access our site (http://www.ratocsystems.com/english/) 2. Follow window menu guide to register. 3. Fill out and submit the registration form. 4-2. Software Update and Support -Driver UpdateThe latest driver or utility software are subject to change for improvement or bug fix. You can download the latest version from our web site. (http://www.
Appendix Copyright ©2002 RATOC Systems,Inc. All rights reserved. No part of this publication may be reproduced, store in a retrieval system, or transmitted in any form or by any means(electronic, mechanical, photocopying, recording or otherwise) without the prior written consent of RATOC Systems,Inc. Trademarks -Windows is a registered trademark of Microsoft Corporation. -Other brand and product names may be registered trademarks or trademarks of their respective holders.
