This screenshot shows the same menu as in the previous screenshot, the only difference being there is now a battery
installed in the PiJuice.
Wakeup Alarm Menu
In this screenshot we have moved over to the Wakeup alarm tab of the config menu and as you can see this is an area where
you can set schedules for the Pi to automatically wake up. This is useful for remote monitoring applications.
This feature will only work if you are either plugged in to the PiJuice microUSB / running on battery. If the battery is low and
you are plugged in via the Raspberry Pis GPIO the only way to enable this feature is by soldering the optional "spring pin"
that comes with the PiJuice HAT.
System Task Menu
