Datasheet

ERA-CONNECT2-PI
easyRadio Advanced Connect2Pi Datasheet 1.2
Page 2 of 3
Specifications
Supply: +5V ± 5%, Temperature 20°C
Parameter
Min
Typical
/Default
Max
Units
Notes
Supply Voltage
5V
Volts
Powered by USB connection
Supply Current
25
mA
Receive (Idle state)
35
mA
Transmit
USB Host Data Rate
2.4
19.2
115.2
Kbps
Configurable - See Note 1 below
Packet Size
1
180
Bytes
Auto detect end of packet
Frequency (Default)
869.75
MHz
Europe - Configurable
915
MHz
USA - Configurable
Receive Sensitivity
-107
-117
dBm
Configurable
RF Output Power
-1
+5
+7
dBm
Configurable
Antenna
50
Ω
Via SMA Connector
Range
200
m
Dependant on conditions/terrain
Operating Temperature
-40
20
85
°C
Mechanical
Size
80 x 22 x 10
mm
Including connectors, excluding antenna
Weight
11
g
Without antenna
USB Connector
USB Type A Plug
Cable not supplied
Notes
1) Parameters can be configured using ‘easyRadio Companion’ software available from: www.lprs.co.uk
2) Please read this datasheet in conjunction with the easyRadio Advanced datasheet available from
www.lprs.co.uk
3) The device is supplied with a 868/915 MHz ¼ Wave whip Antenna
FTDI offers royalty-free virtual com port drivers for the following operating systems:
Windows 98, 98SE, ME, 2000, Server 2003, XP and Server 2008
Windows 7 32,64-bit
Windows XP and XP 64-bit
Windows Vista and Vista 64-bit
Windows XP Embedded Windows CE 4.2, 5.0 and 6.0
Mac OS 8/9, OS-X
Linux 2.4 and greater
LPRS Part Number:
ERA-CONNECT2-PI (Includes ERA900TRS transceiver)
Acknowledgements
Raspberry Pi is a trademark of the Raspberry Pi Foundation.
