Data Sheet

www.rs-online.com/raspberrypi
Raspberry Pi
Camera Module
Product Name Raspberry Pi Camera Module
Product Description High Denition camera module compatible with all Raspberry Pi models.
Provides high sensitivity, low crosstalk and low noise image capture in an ultra
small and lightweight design. The camera module connects to the Raspberry
Pi board via the CSI connector designed specically for interfacing to cameras.
The CSI bus is capable of extremely high data rates, and it exclusively carries
pixel data to the processor.
RS Part Numer 913-2664
Specications
Image Sensor Sony IMX 219 PQ CMOS image sensor in a xed-focus module.
Resolution 8-megapixel
Still picture resolution 3280 x 2464
Max image transfer rate 1080p: 30fps (encode and decode)
720p: 60fps
Connection to Raspberry Pi 15-pin ribbon cable, to the dedicated 15-pin MIPI Camera Serial Interface
(CSI-2).
Image control functions Automatic exposure control
Automatic white balance
Automatic band lter
Automatic 50/60 Hz luminance detection
Automatic black level calibration
Temp range Operating: -20º to 60º
Stable image: -20º to 60º
Lens size 1/4”
Dimensions 23.86 x 25 x 9mm
Weight 3g
