Datasheet

Figure 6. Popcorn
running on the VGA
Board (Average
Current)
Figure 7. Popcorn
running on the VGA
Board (Maximum
Current)
Table 2. Popcorn
running on the VGA
Board (VGA video, SD
Card and I2S audio)
with power saving
disabled (GPIO23
pulled high)
Pico Board
Average VBUS Current @ 5V (mA) Maximum VBUS Current @5V (mA)
Temperature (°C) Temperature (°C)
-25 25 85 -25 25 85
#1 90.3 89.3 90.7 94.6 94.5 95.6
#2 91.2 87.1 90.6 95.4 91.0 95.5
#3 90.8 90.2 91.6 95.0 95.1 95.3
Mean 90.8 88.9 91.0 95.0 93.5 95.5
Raspberry Pi Pico Datasheet
3.1. Power Consumption 12
