Data Sheet

Raspberry Pi Sense HAT
Fact Sheet
Description
The Raspberry Pi Sense HAT is attached on top of the
Raspberry Pi via the 40 GPIO pins (which provide the data
and power interface) to create an ‘Astro Pi’. The Sense HAT
has several integrated circuit based sensors that you can
use for many different types of experiments, applications,
and even games.
Technical Specification
• Gyroscope – angular rate sensor: ±245/500/2000dps
• Accelerometer - Linear acceleration sensor: ±2/4/8/16 g
• Magnetometer - Magnetic Sensor: ±4/8/12/16 gauss
• Barometer: 260 – 1260 hPa absolute range (accuracy depends on the temperature and
pressure, ±0.1 hPa under normal conditions)
• Temperature sensor (Temperature accurate to ± 2 °C in the 0-65 °C range)
• Relative Humidity sensor (accurate to ±4.5% in the 20-80%rH range, accurate to ± 0.5 °C in 15-
40 °C range)
• 8x8 LED matrix display
• Small 5 button joystick
