CHAPTER 12: ADVANCED ADMINISTRATION 149

Firmware Manager

CC-SG stores firmware for Raritan devices in order to update the devices under its control. The

firmware manager is used to upload and delete device firmware files to and from CC-SG.

Upload Firmware

This command allows you to upload different versions of firmware to your system. When new

firmware versions become available, they are posted on the Raritan website.

1. On the Administration menu, click Firmware. The Firmware Manager screen appears.

Figure 148 Firmware Manager Screen

2. Click Add to add a new firmware file. A search window appears.

Figure 149 Firmware Search Window

3. Click the Look In drop-down arrow and navigate to locate the firmware file in your system.

When you find the firmware, select it, and then click Open. Once added, the firmware name

will appear in the Firmware Name field of the Firmware Manager.
