Product Manual

3)
tubing and fully against the
shoulder
water will help this process)
1) CUT the tubing square
with the cutter, ROTATING
wrist while cutting
Tools and installation
Front of block is ported
1/2” NPT Female
Coupler Not Included
M7580 MASTER KIT PARTS LIST
- 300ft ¾” Maxline Tubing
- (3) M81010 Aluminum Blocks
- (3) M8005 ¾” Tubing x 1/2” NPT fittings
- (3) 50136 ½” npt Plugs
- (3) 50120 3/8” npt Drain Valves
- (1) M8003 ¾” Tubing x ¾” NPT Fitting
- (2) M8011 Tee Fittings
- (20) Tubing Clips
- Cutter and Bevel Tool
4)
Put a reference mark on the nut
5) TIGHTEN nut with wrench a
minimum 3/4 of a turn
or until tight
2) BEVEL the inside of the
tubing by inserting the
reaming tool and rotating it
at least 3 full turns
- Use peg #25 for 3/4” tubing
Remove nut and split ring from
Split Ring
(2) ORings
Nut
WARNINGS
• Regulate system pressure to a maximum of 200 psi.
• Pressurize system slowly
• Turn off air compressor when not in use
Check local building codes before installation.
• Compressed air is dangerous if not used properly.
• Do not point compressed air source at any part of your body or at any person.
• Always use eye protection when using compressed air.
• CA PROP 65: This product contains chemicals, including lead, known to the State of California
to cause birth defects or other reproductive harm. Wash hands after handling.
Engineered Specialties, LLC • Auburndale, WI • 800-954-3310
For installation tips and warranty information, please visit www.RapidAirproducts.com
7-2016 REV5
CONTAINS LEAD: MAY BE HARMFUL IF EATEN OR CHEWED. MAY GENERATE
DUST CONTAINING LEAD. KEEP OUT OF THE REACH OF CHILDREN.
