32
Key
No.
Description Part Number
Boiler Model
RRG062 RRG096 RRG130 RRG164
Base Assembly
6 Base Tray
718600391 1 --- --- ---
718600491 --- 1 --- ---
718600591 --- --- 1 ---
718600691 --- --- --- 1
7 Base Wrapper
718600311 1 --- --- ---
718600411 --- 1 --- ---
718600511 --- --- 1 ---
718600611 --- --- --- 1
8 Base Side Insulation 720601 2 2 2 2
9 Base Rear Insulation
72060035 1 --- --- ---
72060045 --- 1 --- ---
72060055 --- --- 1 ---
72060065 --- --- --- 1
10 Base Front Panel Assembly
618600341 1 --- --- ---
618600441 --- 1 --- ---
618600541 --- --- 1 ---
618600641 --- --- --- 1
11 Base Leg Assembly 6186001 4 4 4 4
12 Base Leg 71860021 4 4 4 4
13 Nylon Glide 8186006 4 4 4 4
14 Burner Access Panel
718600361 1 --- --- ---
718600461 --- 1 --- ---
718600561 --- --- 1 ---
718600661 --- --- --- 1
15 Self-Tapping Screw ¼ - 20 x ½ 80860700 20 20 20 20
16 Self-Tapping Screw 5/16 - 18 x 1¼ 80860717 4 4 4 4
17 Flat Washer 5/16", USS 80860601 4 4 4 4
18 Hex Lock Nut 5/16 - 18 80860464 4 4 4 4
19
Cerafelt Sealing Strip ½" x 2" x 10'
(Section Assembly to Base)
6206002 1 1 1 1
