Technical data

51
2.2. Machine equipment
Legend:
A6HPLDXWRPDWLFV\VWHPPDQXDOGLVSHQVLQJVWDUW
and stop.
B$XWRPDWLFV\VWHPHOHFWURQLFFRQWURORIFRIIHH
and hot water doses dispensed.
C N. of coffee dispensing units.
D N. of steam spouts.
E N. of hot water spouts.
1 Steam tap
2 Steam spout
3 ISTEAM button panel (Mod.DE)
4 ISTEAM steam jet (Mod.DE)
5 Coffee dispensing unit
6 Coffee dispensing button panel (Mod.S - DE)
 0DQXDOZDWHUVXSSO\EXWWRQ
8 Level indicator
9 Gauge
10 Power on-off switch and led
11 Switch and boiler resistance engagement light.
 +RWZDWHUNH\
 'LVSOD\0RG'(
14 Programming panel (Mod.DE)
15 Hot water spout
16 Cup heating resistance switch
2. DESCRIPTION
The machines in the CLASSE 8 series have been
designed to prepare express coffee and hot beve-
rages.
A positive-displacement pump inside the machine
SRZHUVWKHKHDWHULQZKLFKWKHZDWHULVKHDWHG%\
pressing the appropriate buttons, water is supplied
to the spouts in the form of hot water or steam, ac-
cording to needs.
The hot water used to make drinks comes from the
boiler.
7KHPDFKLQHLVFRPSRVHGRIDVWHHOFDUU\LQJVWUXF-
ture on which the mechanical and electrical compo-
QHQWVDUH¿WWHG7KHVHDUHFRPSOHWHO\FRYHUHGZLWK
panels made of plastic and steel.
The beverages are dispensed at the front of the
machine, where all the buttons, control devices and
dispensers are to be found.
There is a cup-warming plate on the top of the ma-
chine.
2.1. Specifications and composition (Fig.3)
A B C D
E
DE
- ok 1 - 2 - 3 - 4 2 1
S
ok
-
1 - 2 - 3 - 4 2 1
1 GROUP 2 GROUP 3 GROUP 4 GROUP
1 dose filter holde
1 1 1 1
2 dose filter holde
1 2 3 4
Filters
2 3 4 5
1 mt. supply pipe
1 1 1 1
1,5 mt. supply pipe
1 1 1 1
1,5 mt. drainage pipe
1 1 1 1
Pipe connections
1 1 1 1
Blind disks for cleaning
1 2 3 4
Doser and presser
1 1 1 1
Instruction manual
1 1 1 1
Brush
1 1 1 1
