Timer 3 Registers
Timer 3 Mode Register (T3M) Address: "B"hex - Subaddress: "0"hex
Note: 1. In this mode, the SSI can be used only as demodulator (8-bit NRZ rising edge). All
other SSI modes are not allowed.
Bit 3Bit 2Bit 1Bit 0
T3M3 T3M2 T3M1 T3M0 Reset value: 1111b
T3M3 Timer 3 Mode select bit 3
T3M2 Timer 3 Mode select bit 2
T3M1 Timer 3 Mode select bit 1
T3M0 Timer 3 Mode select bit 0
Mode T3M3 T3M2 T3M1 T3M0 Timer 3 Modes
11111Timer/counter with a read access
21110Timer/counter, external capture and external
trigger restart mode (T3I)
31101Timer/counter, internal capture and internal
trigger restart mode (TOG2)
41100Timer/counter mode 1 without output
(T2O -> T3O)
51011Timer/counter mode 2 without output
(T2O -> T3O)
61010Burst modulation with Timer 2 (M2)
71001Burst modulation with shift register (SO)
81000FSK modulation with shift register (SO)
90111Pulse-width modulation with shift register (SO)
and Timer 2 (TOG2), internal trigger restart
(SCO) -> counter reset
100110Manchester demodulation/pulse-width
demodulation
(1)
(T2O -> T3O)
110101Biphase demodulation (T2O -> T3O)
120100Timer/counter with external capture mode (T3I)
130011Not allowed
140010Not allowed
150001Not allowed
160000Not allowed
