47
T48C862-R8
4590B–4BMCU–02/03
Figure 39. Timer 2 Modulator Output Stage
Timer 2 Output Signals
Timer 2 Output Mode 1 Toggle Mode A: A Timer 2 compare match toggles the output flip-flop (M2) -> T2O
Figure 40. Interrupt Timer/Square Wave Generator – the Output Toggles with Each
Edge Compare Match Event
Toggle Mode B: A Timer 2 compare match toggles the output flip-flop (M2) -> T2O
Figure 41. Pulse Generator – the Timer Output Toggles with the Timer Start if the
T2TS-bit Is Set
Toggle
RES/SET
Biphase/
Manchester
modulator
T2TOPT2OS2, 1, 0T2M2
T2O
M2
M2
S1
S2
S3
Modulator3
RE
FE
OMSK
SSI
CONTROL
TOG2
SO
DCGO
4000123 40123 40123 01
Input
Counter 2
T2R
Counter 2
CMx
INT4
T2O
4000123 567 40123 56
Input
Counter 2
T2R
Counter 2
CMx
INT4
T2O
Toggle
by start
T2O
4095/
255
