Timer 1 Control Register 1
(T1C1)
Address: "7"hex - Subaddress: "8"hex
* Bit 3 -> MSB, Bit 0 -> LSB
The three bits T1C[2:0] select the divider for timer 1. The resulting time interval depends
on this divider and the timer 1 input clock source. The timer input can be supplied by the
system clock, the 32-kHz oscillator or via the clock management. If the clock manage-
ment generates the SUBCL, the selected input clock from the RC oscillator, 4-MHz
oscillator or an external clock is divided by 16.
Bit 3 * Bit 2 Bit 1 Bit 0
T1RM T1C2 T1C1 T1C0 Reset value: 1111b
T1RM Timer 1 Restart Mode T1RM = 0, write access without Timer 1 restart
T1RM = 1, write access with Timer 1 restart
Note: If WDL = 0, Timer 1 restart is impossible
T1C2 Timer 1 Control bit 2
T1C1 Timer 1 Control bit 1
T1C0 Timer 1 Control bit 0
T1C2 T1C1 T1C0 Divider
Time Interval with
SUBCL
Time Interval with
SUBCL = 32 kHz
Time Interval with
SYSCL = 2/1 MHz
0 0 0 2 SUBCL/2 61 µs 1 µs/2 µs
0 0 1 4 SUBCL/4 122 µs 2 µs/4 µs
0 1 0 8 SUBCL/8 244 µs 4 µs/8 µs
0 1 1 16 SUBCL/16 488 µs 8 µs/16 µs
1 0 0 32 SUBCL/32 0.977 ms 16 µs/32 µs
1 0 1 256 SUBCL/256 7.812 ms 128 µs/256 µs
1 1 0 2048 SUBCL/2048 62.5 ms 1024 µs/2048 µs
1 1 1 16384 SUBCL/16384 500 ms 8192 µs/16384 µs
