Table 1. Interrupt Priority
Table 2. Hardware Interrupts
Software Interrupts The programmer can generate interrupts by using the software interrupt instruction
(SWI), which is supported in qFORTH by predefined macros named SWI0...SWI7. The
software triggered interrupt operates exactly like any hardware triggered interrupt. The
SWI instruction takes the top two elements from the expression stack and writes the cor-
responding bits via the I/O bus to the interrupt pending register. Therefore, by using the
SWI instruction, interrupts can be re-prioritized or lower priority processes scheduled for
later execution.
Hardware Interrupts In the microcontroller block, there are eleven hardware interrupt sources with seven
different levels. Each source can be masked individually by mask bits in the correspond-
ing control registers. An overview of the possible hardware configurations is shown in
Table 3.
Interrupt Priority ROM Address Interrupt Opcode Function
INT0 Lowest 040h C8h (SCALL 040h) Software interrupt (SWI0)
INT1 | 080h D0h (SCALL 080h)
External hardware interrupt, any edge at BP52 or
BP53
INT2 | 0C0h D8h (SCALL 0C0h) Timer 1 interrupt
INT3 | 100h E8h (SCALL 100h)
SSI interrupt or external hardware interrupt at BP40
or BP43
INT4 | 140h E8h (SCALL 140h) Timer 2 interrupt
INT5 | 180h F0h (SCALL 180h) Timer 3 interrupt
INT6
| 1C0h F8h (SCALL 1C0h)
External hardware interrupt, at any edge at BP50 or
BP51
INT7 Highest 1E0h FCh (SCALL 1E0h) Voltage monitor (VM) interrupt
Interrupt
Interrupt Mask
Interrupt SourceRegister Bit
INT1 P5CR
P52M1, P52M2
P53M1, P53M2
Any edge at BP52
any edge at BP53
INT2 T1M T1IM Timer 1
INT3 SISC SIM SSI buffer full/empty or BP40/BP43 interrupt
INT4 T2CM T2IM Timer 2 compare match/overflow
INT5
T3CM1
T3CM2
T3C
T3IM1
T3IM2
T3EIM
Timer 3 compare register 1 match
Timer 3 compare register 2 match
Timer 3 edge event occurs (T3I)
INT6 P5CR
P50M1, P50M2
P51M1, P51M2
Any edge at BP50,
any edge at BP51
INT7 VCM VIM External/internal voltage monitoring
