Electrical Parameter：
Maximum（not at working mode）
symbol parameter minimum maximum Unit
V
dd
Positive power supply -0.5 6.0 V
V
in
All pin input level -0.5 Vdd+0.5 V
I
in
Input current except power -25 25 mA
ESD Human body model 1000 V
T
st
Storage temperature -55 125
℃
T
ld
Soldering temperature(10s) 260
℃
Recommended working range
symbol parameter minimum maximum Unit
V
dd
Positive power supply 2.2 5.4 V
T
op
Working temperature -40 85
℃
DC characteristic
symbol parameter Remark minimum typical maximum Unit
I
dd_TX_0
Supply current
(TX mode, P
out
= 0dBm)
315,433MHz band
868MHz band
915MHz band
13
16
17
mA
I
dd_TX_PMAX
Supply current
(TX mode, P
out
= P
max
)
315,433MHz band
868MHz band
915MHz band
21
24
25
mA
I
dd_RX
Supply current
(RX mode)
315,433MHz band
868MHz band
915MHz band
10
12
13
mA
I
x
Stand by current Crystal and base band
on
3．0 3．5
mA
I
pd
Sleep mode current All blocks off 0.3 uA
I
lb
Low battery detection 0.5 uA
V
lb
Low battery step 0.1V per step 2.2 5.3 V
V
lba
Low battery detection
accuracy
75 mV
V
il
Low level input 0.3*V
dd
V
V
ih
High level input 0.7*V
dd
V
I
il
Leakage current V
il
=0V -1 1 uA
I
ih
Leakage current V
ih
=V
dd
, V
dd
=5.4V -1 1 uA
V
ol
Low level output I
ol
=2mA 0.4 V
V
oh
High level output I
oh
=-2mA V
dd
-0.4 V
