MAX9595
Audio/Video Switch for Dual SCART Connector
______________________________________________________________________________________ 19
BIT
DESCRIPTION
76543210
COMMENTS
00
Encoder audio
01
VCR audio
10
TV audio
Input Source for TV Audio
11
Mute (power-on default)
00
Encoder audio
01
VCR audio
10
TV audio
Input Source for VCR Audio
11
Mute (power-on default)
0
Clear INTERRUPT_OUT (power-on
default)
Interrupt Enable
1
Enable INTERRUPT_OUT
00
0dB gain (power-on default)
01
+6dB gain
10
-6dB gain
VCR Volume Control
11
0dB gain
Table 6. Register 01h: TV/VCR Audio Control
