MAX2642/MAX2643
900MHz SiGe, High IP3,
Low-Noise Amplifiers
14 ______________________________________________________________________________________
Table 10. Gain Selection and Shutdown
Modes
PART
CONTROL
VOLTAGE = V
CC
CONTROL
VOLTAGE = 0
MAX2642 Low Gain High Gain
MAX2643 Enabled Shutdown
MAX2642
BIAS
R
BIAS
R
BIAS
(A)
MAX2642
BIAS
(B)
Figure 1. MAX2642 Recommended Shutdown Configurations
Chip Information
TRANSISTOR COUNT: 158
