8-bit Timer/Counter

Timer/Counter Control

• Bit 7 – FOC0: Force Output Compare

The FOC0 bit is only active when the WGM00 bit specifies a non-PWM mode. However,

for ensuring compatibility with future devices, this bit must be set to zero when TCCR0 is

written when operating in PWM mode. When writing a logical one to the FOC0 bit, an

immediate Compare Match is forced on the Waveform Generation unit. The OC0 output

is changed according to its COM01:0 bits setting. Note that the FOC0 bit is implemented

as a strobe. Therefore it is the value present in the COM01:0 bits that determines the

effect of the forced compare.

A FOC0 strobe will not generate any interrupt, nor will it clear the timer in CTC mode

using OCR0 as TOP.

The FOC0 bit is always read as zero.

• Bit 6, 3 – WGM01:0: Waveform Generation Mode

These bits control the counting sequence of the counter, the source for the maximum

(TOP) counter value, and what type of waveform generation to be used. Modes of oper-

ation supported by the Timer/Counter unit are: Normal mode, Clear Timer on Compare

match (CTC) mode, and two types of Pulse Width Modulation (PWM) modes. See Table

47 and “Modes of Operation” on page 93.

Note: 1. The CTC0 and PWM0 bit definition names are now obsolete. Use the WGM01:0 def-

initions. However, the functionality and location of these bits are compatible with

previous versions of the timer.

• Bit 5:4 – COM01:0: Compare Match Output Mode

These bits control the output compare pin (OC0) behavior. If one or both of the

COM01:0 bits are set, the OC0 output overrides the normal port functionality of the I/O

pin it is connected to. However, note that the Data Direction Register (DDR) bit corre-

sponding to the OC0 pin must be set in order to enable the output driver.

Bit 76543210

FOC0 WGM00 COM01 COM00 WGM01 CS02 CS01 CS00 TCCR0

Read/Write W R/W R/W R/W R/W R/W R/W R/W

Initial Value 0 0 0 0 0 0 0 0

Table 47. Waveform Generation Mode Bit Description

(1)

Mode

WGM01

(CTC0)

WGM00

(PWM0)

Timer/Counter Mode

of Operation TOP

Update of

OCR0 at

TOV0 Flag

Set on

0 0 0 Normal 0xFF Immediate MAX

1 0 1 PWM, Phase Correct 0xFF TOP BOTTOM

2 1 0 CTC OCR0 Immediate MAX

3 1 1 Fast PWM 0xFF TOP MAX
