ATmega162/V

2513E–AVR–09/03

General Interrupt Control

• Bit 7 – INT1: External Interrupt Request 1 Enable

When the INT1 bit is set (one) and the I-bit in the Status Register (SREG) is set (one),

the external pin interrupt is enabled. The Interrupt Sense Control1 bits 1/0 (ISC11 and

ISC10) in the MCU general Control Register (MCUCR) define whether the external

interrupt is activated on rising and/or falling edge of the INT1 pin or level sensed. Activity

on the pin will cause an interrupt request even if INT1 is configured as an output. The

corresponding interrupt of External Interrupt Request 1 is executed from the INT1 Inter-

rupt Vector.

• Bit 6 – INT0: External Interrupt Request 0 Enable

When the INT0 bit is set (one) and the I-bit in the Status Register (SREG) is set (one),

the external pin interrupt is enabled. The Interrupt Sense Control0 bits 1/0 (ISC01 and

ISC00) in the MCU general Control Register (MCUCR) define whether the external

interrupt is activated on rising and/or falling edge of the INT0 pin or level sensed. Activity

on the pin will cause an interrupt request even if INT0 is configured as an output. The

corresponding interrupt of External Interrupt Request 0 is executed from the INT0 Inter-

rupt Vector.

• Bit 5 – INT2: External Interrupt Request 2 Enable

When the INT2 bit is set (one) and the I-bit in the Status Register (SREG) is set (one),

the external pin interrupt is enabled. The Interrupt Sense Control2 bit (ISC2) in the

Extended MCU Control Register (EMCUCR) defines whether the external interrupt is

activated on rising or falling edge of the INT2 pin. Activity on the pin will cause an inter-

rupt request even if INT2 is configured as an output. The corresponding interrupt of

External Interrupt Request 2 is executed from the INT2 Interrupt Vector.

• Bit 4 – PCIE1: Pin Change Interrupt Enable 1

When the PCIE1 bit is set (one) and the I-bit in the Status Register (SREG) is set (one),

pin change interrupt 1 is enabled. Any change on any enabled PCINT15..8 pin will

cause an interrupt. The corresponding interrupt of Pin Change Interrupt Request is exe-

cuted from the PCI1 Interrupt Vector. PCINT15..8 pins are enabled individually by the

PCMSK1 Register.

• Bit 3 – PCIE0: Pin Change Interrupt Enable 0

When the PCIE0 bit is set (one) and the I-bit in the Status Register (SREG) is set (one),

pin change interrupt 0 is enabled. Any change on any enabled PCINT7..0 pin will cause

an interrupt. The corresponding interrupt of Pin Change Interrupt Request is executed

from the PCI0 Interrupt Vector. PCINT7..0 pins are enabled individually by the PCMSK0

Bit 76543210

INT1 INT0 INT2 PCIE1 PCIE0

– IVSEL IVCE GICR

Read/Write R/W R/W R/W R/W R/W R R/W R/W

Initial Value00000000
