OC3B, Output Compare Match B output: The PB4 pin can serve as an external output

for the Timer/Counter3 Output Compare B. The pin has to be configured as an output

(DDB4 set (one)) to serve this function. The OC3B pin is also the output pin for the PWM

mode timer function.

• AIN1/TXD1 – Port B, Bit 3

AIN1, Analog Comparator Negative input. Configure the port pin as input with the inter-

nal pull-up switched off to avoid the digital port function from interfering with the function

of the Analog Comparator.

TXD1, Transmit Data (Data output pin for USART1). When the USART1 Transmitter is

enabled, this pin is configured as an output regardless of the value of DDB3.

• AIN0/RXD1 – Port B, Bit 2

AIN0, Analog Comparator Positive Input. Configure the port pin as input with the internal

pull-up switched off to avoid the digital port function from interfering with the function of

the Analog Comparator.

RXD1, Receive Data (Data input pin for USART1). When the USART1 Receiver is

enabled this pin is configured as an input regardless of the value of DDB2. When the

USART1 forces this pin to be an input, the pull-up can still be controlled by the PORTB2

bit.

• T1/OC2 – Port B, Bit 1

T1, Timer/Counter1 Counter Source.

OC2, Output Compare Match output: The PB1 pin can serve as an external output for

the Timer/Counter2 Compare Match. The PB1 pin has to be configured as an output

(DDB1 set (one)) to serve this function. The OC2 pin is also the output pin for the PWM

mode timer function.

• T0/OC0 – Port B, Bit 0

T0, Timer/Counter0 counter source.

OC0, Output Compare Match output: The PB0 pin can serve as an external output for

the Timer/Counter0 Compare Match. The PB0 pin has to be configured as an output

(DDB0 set (one)) to serve this function. The OC0 pin is also the output pin for the PWM

mode timer function.

clk

I/O

, Divided System Clock: The divided system clock can be output on the PB0 pin.

The divided system clock will be output if the CKOUT Fuse is programmed, regardless

of the PORTB0 and DDB0 settings. It will also be output during reset.

Table 33 and Table 34 relate the alternate functions of Port B to the overriding signals

shown in Figure 32 on page 67. SPI MSTR INPUT and SPI SLAVE OUTPUT constitute

the MISO signal, while MOSI is divided into SPI MSTR OUTPUT and SPI SLAVE

INPUT.
