ATmega162/V

2513E–AVR–09/03

Table 28 summarizes the function of the overriding signals. The pin and port indexes

from Figure 32 are not shown in the succeeding tables. The overriding signals are gen-

erated internally in the modules having the alternate function.

The following subsections shortly describe the alternate functions for each port, and

relate the overriding signals to the alternate function. Refer to the alternate function

description for further details.

Table 28. Generic Description of Overriding Signals for Alternate Functions.

Signal Name Full Name Description

PUOE Pull-up Override

Enable

If this signal is set, the pull-up enable is controlled by the

PUOV signal. If this signal is cleared, the pull-up is

enabled when {DDxn, PORTxn, PUD} = 0b010.

PUOV Pull-up Override

Value

If PUOE is set, the pull-up is enabled/disabled when

PUOV is set/cleared, regardless of the setting of the

DDxn, PORTxn, and PUD Register bits.

DDOE Data Direction

Override Enable

If this signal is set, the Output Driver Enable is controlled

by the DDOV signal. If this signal is cleared, the Output

driver is enabled by the DDxn Register bit.

DDOV Data Direction

Override Value

If DDOE is set, the Output Driver is enabled/disabled

when DDOV is set/cleared, regardless of the setting of the

DDxn Register bit.

PVOE Port Value

Override Enable

If this signal is set and the Output Driver is enabled, the

port value is controlled by the PVOV signal. If PVOE is

cleared, and the Output Driver is enabled, the port Value is

controlled by the PORTxn Register bit.

PVOV Port Value

Override Value

If PVOE is set, the port value is set to PVOV, regardless of

the setting of the PORTxn Register bit.

DIEOE Digital Input

Enable Override

Enable

If this bit is set, the Digital Input Enable is controlled by the

DIEOV signal. If this signal is cleared, the Digital Input

Enable is determined by MCU state (Normal Mode, Sleep

Modes).

DIEOV Digital Input

Enable Override

Value

If DIEOE is set, the Digital Input is enabled/disabled when

DIEOV is set/cleared, regardless of the MCU state

(Normal Mode, Sleep Modes).

DI Digital Input This is the Digital Input to alternate functions. In the figure,

the signal is connected to the output of the schmitt trigger

but before the synchronizer. Unless the Digital Input is

used as a clock source, the module with the alternate

function will use its own synchronizer.

AIO Analog

Input/output

This is the Analog Input/output to/from alternate functions.

The signal is connected directly to the pad, and can be

used bi-directionally.
