• Bit 2 – BORF: Brown-out Reset Flag
This bit is set if a Brown-out Reset occurs. The bit is reset by a Power-on Reset, or by
writing a logic zero to the flag.
• Bit 1 – EXTRF: External Reset Flag
This bit is set if an External Reset occurs. The bit is reset by a Power-on Reset, or by
writing a logic zero to the flag.
• Bit 0 – PORF: Power-on Reset Flag
This bit is set if a Power-on Reset occurs. The bit is reset only by writing a logic zero to
the flag.
To make use of the Reset Flags to identify a reset condition, the user should read and
then Reset the MCUCSR as early as possible in the program. If the register is cleared
before another reset occurs, the source of the Reset can be found by examining the
Reset Flags.
Internal Voltage
Reference
ATmega162 features an internal bandgap reference. This reference is used for Brown-
out Detection, and it can be used as an input to the Analog Comparator.
Voltage Reference Enable
Signals and Start-up Time
The voltage reference has a start-up time that may influence the way it should be used.
The start-up time is given in Table 21. To save power, the reference is not always turned
on. The reference is on during the following situations:
1. When the BOD is enabled (by programming the BODLEVEL Fuses).
2. When the bandgap reference is connected to the Analog Comparator (by setting
the ACBG bit in ACSR).
Thus, when the BOD is not enabled, after setting the ACBG bit, the user must always
allow the reference to start up before the output from the Analog Comparator is used. To
reduce power consumption in Power-down mode, the user can avoid the two conditions
above to ensure that the reference is turned off before entering Power-down mode.
Watchdog Timer The Watchdog Timer is clocked from a separate On-chip Oscillator which runs at
1 MHz. This is the typical frequency at V
CC
= 5V. See characterization data for typical
values at other V
CC
levels. By controlling the Watchdog Timer prescaler, the Watchdog
Reset interval can be adjusted as shown in Table 23 on page 53. The WDR – Watchdog
Reset – instruction resets the Watchdog Timer. The Watchdog Timer is also reset when
it is disabled and when a Chip Reset occurs. Eight different clock cycle periods can be
selected to determine the reset period. If the reset period expires without another
Watchdog Reset, the ATmega162 resets and executes from the Reset Vector. For tim-
ing details on the Watchdog Reset, refer to page 53.
To prevent unintentional disabling of the Watchdog or unintentional change of time-out
period, 3 different safety levels are selected by the Fuses M161C and WDTON as
Table 21. Internal Voltage Reference Characteristics
Symbol Parameter Min. Typ. Max. Units
V
BG
Bandgap reference voltage 1.05 1.10 1.15 V
t
BG
Bandgap reference start-up time 40 70 µs
I
BG
Bandgap reference current
consumption
10 µA
