ATmega162/V

2513E–AVR–09/03

Extended MCU Control

• Bit 7 – SM0: Sleep Mode Select Bit 0

The Sleep Mode Select bits select between the five available sleep modes as shown in

Table 16.

Note: 1. Standby mode and Extended Standby mode are only available with external crystals

or resonators.

Idle Mode When the SM2..0 bits are written to 000, the SLEEP instruction makes the MCU enter

Idle mode, stopping the CPU but allowing the SPI, USART, Analog Comparator,

Timer/Counters, Watchdog, and the interrupt system to continue operating. This sleep

mode basically halts clk

CPU

and clk

FLASH

, while allowing the other clocks to run.

Idle mode enables the MCU to wake up from external triggered interrupts as well as

internal ones like the Timer Overflow and USART Transmit Complete interrupts. If

wake-up from the Analog Comparator interrupt is not required, the Analog Comparator

can be powered down by setting the ACD bit in the Analog Comparator Control and Sta-

tus Register – ACSR. This will reduce power consumption in Idle mode.

Power-down Mode When the SM2..0 bits are written to 010, the SLEEP instruction makes the MCU enter

Power-down mode. In this mode, the external Oscillator is stopped, while the external

interrupts and the Watchdog continue operating (if enabled). Only an External Reset, a

Watchdog Reset, a Brown-out Reset, an External Level Interrupt on INT0 or INT1, an

external interrupt on INT2, or a pin change interrupt can wake up the MCU. This sleep

mode basically halts all generated clocks, allowing operation of asynchronous modules

only.

Note that if a level triggered interrupt is used for wake-up from Power-down mode, the

changed level must be held for some time to wake up the MCU. Refer to “External Inter-

rupts” on page 83 for details.

When waking up from Power-down mode, there is a delay from the wake-up condition

occurs until the wake-up becomes effective. This allows the clock to restart and become

stable after having been stopped. The wake-up period is defined by the same CKSEL

Fuses that define the Reset Time-out period, as described in “Clock Sources” on page

34.

Bit 76543210

SM0

SRL2 SRL1 SRL0 SRW01 SRW00 SRW11 ISC2 EMCUCR

Read/Write R/W R/W R/W R/W R/W R/W R/W R/W

Initial Value00000000

Table 16. Sleep Mode Select

SM2 SM1 SM0 Sleep Mode

000Idle

001Reserved

0 1 0 Power-down

0 1 1 Power-save

100Reserved

101Reserved

1 1 0 Standby

(1)

1 1 1 Extended Standby

(1)
