- Table of Contents
314
ATmega162/V
2513E–AVR–09/03
Datasheet Change
Log for ATmega162
Please note that the referring page numbers in this section are referred to this docu-
ment. The referring revision in this section are referring to the document revision.
Changes from Rev.
2513D-04/03 to Rev.
2513E-09/03
1. Removed “Preliminary” from the datasheet.
2. Added note on Figure 1 on page 2.
3. Renamed and updated “On-chip Debug System” to “JTAG Interface and
On-chip Debug System” on page 44.
4. Updated Table 18 on page 47 and Table 19 on page 49.
5. Updated “Test Access Port – TAP” on page 196 regarding JTAGEN.
6. Updated description for the JTD bit on page 206.
7. Added note on JTAGEN in Table 100 on page 232.
8. Updated Absolute Maximum Ratings* and DC Characteristics in “Electrical
Characteristics” on page 263.
9. Added a proposal for solving problems regarding the JTAG instruction
IDCODE in “Erratas” on page 313.
Changes from Rev.
2513C-09/02 to Rev.
2513D-04/03
1. Updated the “Ordering Information” on page 309 and “Packaging Informa-
tion” on page 310.
2. Updated “Features” on page 1.
3. Added characterization plots under “ATmega162 Typical Characteristics” on
page 274.
4. Added Chip Erase as a first step under “Programming the Flash” on page 259
and “Programming the EEPROM” on page 261.
5. Changed CAL7, the highest bit in the OSCCAL Register, to a reserved bit on
page 37 and in “Register Summary” on page 303.
6. Changed CPCE to CLKPCE on page 39.
7. Corrected code examples on page 54.
8. Corrected OCn waveforms in Figure 52 on page 119.
9. Various minor Timer1 corrections.
10. Added note under “Filling the Temporary Buffer (Page Loading)” on page 223
about writing to the EEPROM during an SPM Page Load.
11. Added section “EEPROM Write During Power-down Sleep Mode” on page 22.
